NU
ENDO
CO
NSOLE
LA
YOUT
The majority of Nuendo or Cubase functions are controlled via dedicated keys with virtually no reliance on the 8x8 key
matrix located beneath the screen. Full details are available in the Mackie Control and Nuendo document available from
the Nuendo download page.
Major changes compared to the HUI front panel are the new control set for assigning processing parameters to the V-
pots.
Up and down page keys for V-pot parameters are located with the Shift key block. The rotary encoder will also output
the page up/down commands when turned left or right.
RDY and SEL control the function of the Channel SEL key as in the HUI interface. The EDIT key is used to open editing
windows in Nuendo or Cubase for the current selection. EDIT together with SHIFT will close an active window.
CHANNEL is unchanged and assigns the AWS channel gain element or DAW channel to the V-pot according to the state
of the Console Focus key. The Encoder switch is used to ‘flip’ parameters on to the faders as before but now includes all
processing parameters not just send levels.
The Keys above the Motion controls are assigned to related transport functions as on the HUI interface.
The Cycle and Punch tallies are displayed in the status area of the TFT display.
LEFT
CYCLE
PUNCHRIGHT
PREV
NEX T
ADD
DAW Control
AWS δelta Owner’s Manual Page 4-33
