Appendices
AWS δelta Owner’s Manual Appendices Page A-1
APPENDICES
ASPECIFICATIONS
AWS Physical Specifications
Parameter Condition Value Unit Notes
Height To top of meter trim 925 mm
Height adjustment -0 +20 mm
Width 1,445 mm
Depth 873 mm
Weight Including both legs 108 Kg
Each leg 4 Kg
Heat dissipation:
AWS δelta 916
430 W
AWS δelta 924
550 W
AWS δelta 948
650 W
Voltage Input range 100 – 230 V ±10%
Current 7.5 – 3.1 A
Inrush Current Initial 4.6 A
After 5 seconds 4.6 A
Power factor 0.95
Fusing None
Noise Fanless
Connectors: Mains input IEC male
Serial 9-way D-type female
VGA Out HD 15-way D-Type (640 x 480 60Hz)
AWS Performance Specifications
Parameter Path Value Notes
Headroom >+26dBu Onset of clipping
Frequency Microphone input – Insert Send 20Hz–20kHz ±0.2dB 0dB applied, Mic gain at minimum
Response Line input – Direct out 20Hz–20kHz ±0.1dB 0dB applied, Line gain at detent (unity gain)
Line input – Track / Aux Bus out 20Hz–20kHz ±0.1dB “ “
Line input – Mix / Rec out 20Hz–20kHz ±0.1dB “ “
Noise Microphone input – Insert Send <-127dBu Typical EIN. Max mic gain, 20Hz–20kHz filter
Line input – Direct out <-89dBu 20Hz–20kHz filter
Line input – Track / Aux Bus out <-89dBu No channels routed, 20Hz–20kHz filter
<-88dBu One channel routed, 20Hz–20kHz filter
<-77.5dBu All channels routed, 20Hz–20kHz filter
Line input – Mix / Rec out <-91dBu No channels routed, 20Hz–20kHz filter
<-88dBu One channel routed, 20Hz–20kHz filter
<-77.5dBu All channels routed, 20Hz–20kHz filter
THD Line input – Direct out <0.002% +20dBu, 1kHz, 20Hz–80kHz Filter
Line input – Track / Aux Bus out <0.005% “ “
Line input – Mix / Rec out <0.005% “ “
