3-8
BVW-55
SERVO ADJUST
A00-01:SERVO ADJUST
*
SERVO ADJUST
A000:A001-A008 ADJ.
A001:S REEL FG DUTY
A002:CAPSTAN FG DUTY
A003:CAPSTAN FREE SPEED
A005:RF SWITCHING POS.
A006:NV-RAM CONTROL
*
[SET]
[MENU]
A0 : SERVO ADJUST
This submode is used to adjust the servo system.
For more details, refer to the maintenance manual part 2 volume 1.
A1 : BETACAM REC ADJUST
This submode is used to adjust the RF system.
For more details, refer to the maintenance manual part 2 volume 1.
A2 : AUDIO/VIDEO ADJUST
This submode is used to adjust the audio and video systems.
For more details, refer to the maintenance manual part 2 volume 1.
3-2. TAPE Maintenance Mode (M0)
3-2-1. Overviews
RF ADJUST MODE
A12:REC CURRENT
A18:MODULATOR VR 1
A19:MODULATOR VR 2
A1A:MODULATOR VR 3
A1F:NV-RAM CONTROL
*
AUDIO/VIDEO ADJUST MODE
A20:VPR/TG VR
A23:SDI VR
A24:INPUT CF DETECT
A25:DEC VR
A26:DEC VR (LOOP)
A27:VIDEO METER
A2F:NV-RAM CONTROL
*
