STR-DA2800ES
144
Pin No. Pin Name I/O Description
75 ADV_INT2 I Interrupt signal input from the video processor (for HDMI receiver)
76 to 80 NC O Not used
81 ADV_SPIO_SIMO O Serial data output to the video processor
82 ADV_SPIO_SOMI I Serial data input from the video processor
83 ADV_SPIO_CLK O Serial data transfer clock signal output to the video processor
84 ADV_SPIO_CS O Chip select signal output to the video processor
85 DEVICE_I2C_SDA I/O Two-way I2C serial data with the video processor, HDMI transceiver and HDMI input selector
86 NC O Not used
87 DEVICE_I2C_SCL O
I2C serial data transfer clock signal output to the video processor, HDMI transceiver and
HDMI input selector
88 NC O Not used
89 DSD_SEL O DSD selection signal output terminal
90 NC O Not used
91 HDMI_OUT0_5VPWR O Power supply on/off control signal output terminal for HDMI +5V power Not used
92 HDMI_OUT1_5VPWR O
Power supply on/off control signal output terminal for HDMI ZONE 2 OUT connector
“H”: power on
93 to 99 NC O Not used
100 VCC - Power supply terminal (+3.3V)
