STR-DA2800ES
165
NETWORK BOARD IC2601 LM3S615-IQN50-C2T (IR CONTROLLER)
Pin No. Pin Name I/O Description
1, 2 ADC0, ADC1 - Not used
3 PE3/CCP1 O IR enable signal output terminal
4 PE2/CCP4 O IR enable signal output terminal
5 RESETn I Reset signal input from the audio/video signal decoder
6 LDO - External capacitor connection terminal
7 VDD4 - Power supply terminal (+3.3V)
8 GND1 - Ground terminal
9 OSC0 I System clock input terminal (6 MHz)
10 OSC1 O System clock output terminal (6 MHz)
11 PC7/C2– - Not used
12 PC6/C2+/CCP3 - Not used
13 PC5/C1+/C1o O Interrupt signal output to the audio/video signal decoder
14 PC4/CCP5 - Not used
15 VDD3 - Power supply terminal (+3.3V)
16 GND2 - Ground terminal
17 PA0/U0Rx I Serial data input from the RS232C connector
18 PA1/U0Tx O Serial data output to the RS232C connector
19 PA2/SSIClk - Not used
20 PA3/SSIFss - Not used
21 PA4/SSIRx - Not used
22 PA5/SSITx - Not used
23 VDD2 - Power supply terminal (+3.3V)
24 GND3 - Ground terminal
25 PD0/PWM0 O IR signal output terminal
26 PD1/PWM1 - Not used
27 PD2/U1Rx I Serial data input terminal
28 PD3/U1Tx O Serial data output terminal
29 PB0/PWM2 O IR signal output terminal
30 PB1/PWM3 O IR enable signal output terminal
31 GND4 - Ground terminal
32 VDD1 - Power supply terminal (+3.3V)
33 PB2/I2CSCL I I2C serial data transfer clock signal input from the audio/video signal decoder
34 PB3/I2CSDA I/O Two-way I2C serial data bus with the audio/video signal decoder and real time clock
35 PE0/PWM4 O IR enable signal output terminal
36 PE1/PWM5 O IR enable signal output terminal
37 PC3/TDO/SWO O Test data output terminal (for JTAG)
38 PC2/TDI I Test data input terminal (for JTAG)
39 PC1/TMS/SWDIO I Test mode selection signal input terminal (for JTAG)
40 PC0/TCK/SWCLK I Test clock signal input terminal (for JTAG)
41 PB7/TRSTn - Not used
42 PB6/C0+ O IR enable signal output terminal
43 PB5/C1– O IR enable signal output terminal
44 PB4/C0– O IR enable signal output terminal
45 PD4/CCP0 I IR signal input terminal
46 PD5/CCP2 - Not used
47 PD6/Fault - Not used
48 PD7/C0o - Not used
