Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DA2800ES
186
< FUSE >
0 F1402 1-523-086-11 FUSE (3.15 A/250 V)
< IC >
IC1402 6-716-575-01 IC TPS54331GDR
IC1403 6-714-911-01 IC TPS54325PWPR
IC1404 6-716-575-01 IC TPS54331GDR
IC1405 6-716-575-01 IC TPS54331GDR
IC1406 6-716-575-01 IC TPS54331GDR
IC1407 6-702-913-01 IC S-80929CNMC-G8ZT2G
IC1408 6-716-852-01 IC TPS54425PWPR
IC1410 6-718-820-01 IC BD9009HFP-TR
IC3903 (Not supplied) IC ISL8023A
IC3904 (Not supplied) IC ISL8023A
< COIL >
L1402 1-460-586-11 COIL, CHOKE 22uH
L1403 1-457-439-11 CHOKE COIL (SMD) 4.7uH
L1404 1-460-470-11 COIL, CHOKE 22uH
L1405 1-460-470-11 COIL, CHOKE 22uH
L1406 1-460-586-11 COIL, CHOKE 22uH
L1407 1-457-439-11 CHOKE COIL (SMD) 4.7uH
L1411 1-457-995-11 CHOKE COIL 10uH
L1412 1-457-995-11 CHOKE COIL 10uH
L1414 1-457-995-11 CHOKE COIL 10uH
L1415 1-460-586-11 COIL, CHOKE 22uH
L1418 1-457-439-11 CHOKE COIL (SMD) 4.7uH
L1419 1-457-439-11 CHOKE COIL (SMD) 4.7uH
< TRANSISTOR >
Q1402 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1403 8-729-038-23 TRANSISTOR RT1N141C-TP-1
< RESISTOR >
R1401 1-218-941-81 METAL CHIP 100 5% 1/16W
R1402 1-218-941-81 METAL CHIP 100 5% 1/16W
R1403 1-218-941-81 METAL CHIP 100 5% 1/16W
R1404 1-218-941-81 METAL CHIP 100 5% 1/16W
R1405 1-218-941-81 METAL CHIP 100 5% 1/16W
R1406 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R1407 1-208-695-11 METAL CHIP 3.3K 0.5% 1/16W
R1408 1-216-864-11 SHORT CHIP 0
R1409 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R1410 1-216-797-11 METAL CHIP 10 5% 1/10W
R1411 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R1412 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R1413 1-208-943-11 METAL CHIP 220K 0.5% 1/16W
R1414 1-208-663-11 METAL CHIP 150 0.5% 1/16W
R1415 1-216-797-11 METAL CHIP 10 5% 1/10W
R1416 1-208-883-81 METAL CHIP 680 0.5% 1/16W
R1417 1-216-797-11 METAL CHIP 10 5% 1/10W
R1418 1-216-797-11 METAL CHIP 10 5% 1/10W
R1419 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R1420 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R1421 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R1422 1-208-893-11 METAL CHIP 1.8K 0.5% 1/16W
R1423 1-208-883-81 METAL CHIP 680 0.5% 1/16W
R1424 1-208-663-11 METAL CHIP 150 0.5% 1/16W
R1425 1-208-687-11 METAL CHIP 1.5K 0.5% 1/16W
R1426 1-250-535-11 METAL CHIP 47K 1% 1/16W
R1427 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R1428 1-216-864-11 SHORT CHIP 0
R1429 1-208-663-11 METAL CHIP 150 0.5% 1/16W
R1430 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R1431 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R1432 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R1433 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R1434 1-216-797-11 METAL CHIP 10 5% 1/10W
R1436 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R1448 1-216-864-11 SHORT CHIP 0
R1449 1-216-864-11 SHORT CHIP 0
R1450 1-216-864-11 SHORT CHIP 0
R1451 1-216-864-11 SHORT CHIP 0
R1455 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R1456 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1457 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1462 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R1463 1-208-703-11 METAL CHIP 6.8K 0.5% 1/16W
R1464 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R1465 1-216-797-11 METAL CHIP 10 5% 1/10W
R1480 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R1482 1-218-883-11 METAL CHIP 33K 0.5% 1/10W
R1483 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1484 1-218-882-11 METAL CHIP 30K 0.5% 1/10W
R1489 1-216-864-11 SHORT CHIP 0
R1498 1-218-869-11 METAL CHIP 8.2K 0.5% 1/10W
R1504 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R1505 1-208-943-11 METAL CHIP 220K 0.5% 1/16W
R1507 1-250-535-11 METAL CHIP 47K 1% 1/16W
R1508 1-250-535-11 METAL CHIP 47K 1% 1/16W
R1509 1-250-535-11 METAL CHIP 47K 1% 1/16W
R1511 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R1512 1-216-864-11 SHORT CHIP 0
R1513 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R1514 1-208-943-11 METAL CHIP 220K 0.5% 1/16W
R1515 1-208-943-11 METAL CHIP 220K 0.5% 1/16W
R1516 1-208-943-11 METAL CHIP 220K 0.5% 1/16W
R1517 1-208-943-11 METAL CHIP 220K 0.5% 1/16W
R1518 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
*************************************************************
A-1880-314-A DISPLAY BOARD, COMPLETE
***********************
< CAPACITOR >
C109 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C110 1-104-957-11 ELECT 47uF 20% 25V
C112 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C115 1-165-733-31 ELECT 100uF 20% 25V
C117 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C118 1-126-964-11 ELECT 10uF 20% 50V
C119 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C126 1-114-910-91 FILM 0.0039uF 5% 250V
C127 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
C128 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C129 1-165-748-31 ELECT 150uF 20% 50V
C130 1-114-811-11 CERAMIC CHIP 0.0033uF 10% 50V
C131 1-114-811-11 CERAMIC CHIP 0.0033uF 10% 50V
C132 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C134 1-116-405-11 CERAMIC CHIP 0.01uF 10% 100V
Note: IC3903 and IC3904 on the DCDC board cannot exchange with single.
When these parts are damaged, exchange the complete mounted board.
DCDC DISPLAY
