Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DA2800ES
187187
C135 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C137 1-116-405-11 CERAMIC CHIP 0.01uF 10% 100V
C138 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C139 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C140 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C141 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C142 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
< CONNECTOR >
CN104 1-784-930-11 PIN, CONNECTOR 15P
CN105 1-779-799-11 PIN, CONNECTOR 9P
CN106 1-784-925-11 PIN, CONNECTOR 10P
< DIODE >
D104 8-719-049-09 DIODE 1SS367-T3SONY
D105 8-719-049-09 DIODE 1SS367-T3SONY
D106 8-719-049-09 DIODE 1SS367-T3SONY
D107 8-719-049-09 DIODE 1SS367-T3SONY
D109 8-719-053-18 DIODE 1SR154-400TE-25
D110 6-502-978-01 DIODE DA2J10400L
D111 6-502-978-01 DIODE DA2J10400L
D112 6-502-978-01 DIODE DA2J10400L
D113 6-502-978-01 DIODE DA2J10400L
D114 6-502-968-01 DIODE DZ2J062M0L
< IC >
IC101 6-600-768-01 IC PNA4823M03S0 (
)
IC102 8-759-710-97 IC NJM4565M-D
IC103 6-717-098-01 IC TSOP98200
< JACK >
J100 1-843-387-11 PIN JACK 3P (VIDEO 2 IN AUDIO/VIDEO)
< COIL >
L101 1-421-967-11 COIL, CHOKE 100uH
< FLUORESCENT INDICATOR TUBE >
ND101 1-811-613-11 VACUUM FLOURESCENT DISPLAY
< TRANSISTOR >
Q101 6-552-809-01 TRANSISTOR 2SC5566-TD-E
Q102 6-552-809-01 TRANSISTOR 2SC5566-TD-E
< RESISTOR >
R103 1-216-837-11 METAL CHIP 22K 5% 1/10W
R110 1-250-616-11 METAL CHIP 1K 1% 1/10W
R111 1-250-624-11 METAL CHIP 2.2K 1% 1/10W
R112 1-250-640-11 METAL CHIP 10K 1% 1/10W
R114 1-250-624-11 METAL CHIP 2.2K 1% 1/10W
R115 1-250-616-11 METAL CHIP 1K 1% 1/10W
R116 1-250-632-11 METAL CHIP 4.7K 1% 1/10W
R118 1-250-652-11 METAL CHIP 33K 1% 1/10W
R119 1-250-592-11 METAL CHIP 100 1% 1/10W
R121 1-250-568-11 METAL CHIP 10 1% 1/10W
R123 1-250-624-11 METAL CHIP 2.2K 1% 1/10W
R125 1-250-592-11 METAL CHIP 100 1% 1/10W
R126 1-250-584-11 METAL CHIP 47 1% 1/10W
R127 1-250-584-11 METAL CHIP 47 1% 1/10W
R128 1-250-604-11 METAL CHIP 330 1% 1/10W
R129 1-216-296-11 SHORT CHIP 0
R132 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R134 1-216-079-00 METAL CHIP 18K 5% 1/10W
R136 1-250-624-11 METAL CHIP 2.2K 1% 1/10W
R137 1-216-838-11 METAL CHIP 27K 5% 1/10W
R138 1-216-661-11 METAL CHIP 2.7K 0.5% 1/10W
R149 1-216-864-11 SHORT CHIP 0
* R150 1-250-589-11 METAL CHIP 75 1% 1/10W
R151 1-250-624-11 METAL CHIP 2.2K 1% 1/10W
R152 1-250-656-11 METAL CHIP 47K 1% 1/10W
R153 1-250-656-11 METAL CHIP 47K 1% 1/10W
R154 1-250-624-11 METAL CHIP 2.2K 1% 1/10W
R157 1-216-864-11 SHORT CHIP 0
R158 1-250-568-11 METAL CHIP 10 1% 1/10W
R159 1-250-592-11 METAL CHIP 100 1% 1/10W
< SWITCH/ROTARY ENCODER >
S100 1-762-875-21 SWITCH, KEY BOARD (TONE MODE)
S101 1-762-875-21 SWITCH, KEY BOARD (TONE/TUNING –)
S102 1-762-875-21 SWITCH, KEY BOARD (TONE/TUNING +)
S103 1-762-875-21 SWITCH, KEY BOARD (2ch/A.DIRECT)
S104 1-762-875-21 SWITCH, KEY BOARD (A.F.D.)
S105 1-762-875-21 SWITCH, KEY BOARD (MOVIE/HD-D.C.S.)
S106 1-762-875-21 SWITCH, KEY BOARD (MUSIC)
S108 1-418-725-41 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
S109 1-762-875-21 SWITCH, KEY BOARD (DIMMER)
S110 1-762-875-21 SWITCH, KEY BOARD (DISPLAY MODE)
S111 1-762-875-21 SWITCH, KEY BOARD (TUNING MODE)
S112 1-762-875-21 SWITCH, KEY BOARD (MEMORY/ENTER)
< TRANSFORMER >
T101 1-445-015-11 TRANSFORMER, DC-DC CONVERTER
*************************************************************
A-1880-340-A DSP BOARD, COMPLETE
********************
< CAPACITOR >
C5000 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5001 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5002 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5003 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5004 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5005 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5006 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5007 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5008 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C5009 1-114-385-11 ELECT CHIP 470uF 20% 6.3V
C5016 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5017 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5018 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5019 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5020 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5021 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5022 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5023 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5024 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5025 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5026 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5027 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
DISPLAY DSP
