Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DA2800ES
211211
R7024 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R7025 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R7026 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R7027 1-218-953-11 METAL CHIP 1K 5% 1/16W
R7028 1-218-953-11 METAL CHIP 1K 5% 1/16W
R7029 1-218-953-11 METAL CHIP 1K 5% 1/16W
R7030 1-218-953-11 METAL CHIP 1K 5% 1/16W
R7031 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R7032 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R7033 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R7034 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R7051 1-216-864-11 SHORT CHIP 0
R7052 1-216-864-11 SHORT CHIP 0
R7053 1-216-864-11 SHORT CHIP 0
R7054 1-216-864-11 SHORT CHIP 0
R7055 1-218-953-11 METAL CHIP 1K 5% 1/16W
R7056 1-218-953-11 METAL CHIP 1K 5% 1/16W
*************************************************************
SURR SPEAKER BOARD
*******************
< CAPACITOR >
CC15 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
CC17 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
CC18 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
CC62 1-100-153-91 CERAMIC CHIP 220PF 5% 100V
CC63 1-100-153-91 CERAMIC CHIP 220PF 5% 100V
CC64 1-100-153-91 CERAMIC CHIP 220PF 5% 100V
< CONNECTOR >
CN393 1-785-104-11 PIN, CONNECTOR (3.96 mm PITCH) 6P
< RESISTOR >
0 RR15 1-249-393-11 CARBON 10 5% 1/4W F
0 RR17 1-249-393-11 CARBON 10 5% 1/4W F
0 RR18 1-249-393-11 CARBON 10 5% 1/4W F
< TERMINAL >
0 TB502 1-780-405-11 TERMINAL BOARD (SP) (2P)
(SPEAKERS CENTER)
0 TB503 1-780-405-11 TERMINAL BOARD (SP) (2P)
(SPEAKERS SURROUND BACK/
FRONT HIGH/FRONT B/ZONE 2 L)
0 TB504 1-780-745-11 TERMINAL BOARD (SP) (2P)
(SPEAKERS SURROUND BACK/
FRONT HIGH/FRONT B/ZONE 2 R)
*************************************************************
TEMP_SENSOR BOARD
*******************
< CAPACITOR >
C149 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
< RESISTOR >
R166 1-250-624-11 METAL CHIP 2.2K 1% 1/10W
R167 1-250-624-11 METAL CHIP 2.2K 1% 1/10W
< THERMISTOR >
TH100 1-804-045-11 THERMISTOR
TH101 1-804-045-11 THERMISTOR
*************************************************************
A-1880-354-A USB BOARD, COMPLETE
********************
< CAPACITOR >
C4101 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4102 1-100-354-21 ELECT CHIP 220uF 20% 6.3V
C4127 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C4128 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C4129 1-124-779-00 ELECT CHIP 10uF 20% 16V
C4130 1-128-993-21 ELECT CHIP 22uF 20% 10V
C4131 1-164-862-81 CERAMIC CHIP 33PF 5% 50V
C4132 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4133 1-164-862-81 CERAMIC CHIP 33PF 5% 50V
C4134 1-128-993-21 ELECT CHIP 22uF 20% 10V
C4135 1-116-734-11 CERAMIC CHIP 1uF 20% 16V
C4136 1-128-994-21 ELECT CHIP 47uF 20% 10V
C4137 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C4138 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C4161 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4187 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN4101 1-573-290-21 PIN, CONNECTOR (1.5 mm) (SMD) 4P
CN4102 1-784-923-11 PIN, CONNECTOR 7P
< DIODE >
D4121 6-502-961-01 DIODE DA2J10100L
D4161 8-719-049-09 DIODE 1SS367-T3SONY
D4162 8-719-049-09 DIODE 1SS367-T3SONY
< EARTH TERMINAL >
* ET4100 1-780-408-11 TERMINAL, LUG
< FERRITE BEAD >
FB4101 1-469-152-11 FERRITE, EMI (SMD) (2012)
< IC >
IC4121 8-759-710-97 IC NJM4565M-D
< JACK >
J4000 1-819-866-11 USB CONNECTOR (A) (
)
J4100 1-822-453-11 SMALL TYPE JACK (3.5 mm) (AUTO CAL MIC)
< TRANSISTOR >
Q4121 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q4123 6-551-693-01 TRANSISTOR RT3T11M-TP-1
< RESISTOR >
R4132 1-218-941-81 METAL CHIP 100 5% 1/16W
R4133 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R4134 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R4135 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R4136 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R4137 1-218-973-11 METAL CHIP 47K 5% 1/16W
R4138 1-218-953-11 METAL CHIP 1K 5% 1/16W
R4139 1-218-973-11 METAL CHIP 47K 5% 1/16W
SUB D-VIDEO SURR SPEAKER TEMP_SENSOR USB
