Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DA2800ES
212
R4141 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4142 1-218-973-11 METAL CHIP 47K 5% 1/16W
R4143 1-208-702-11 METAL CHIP 6.2K 0.5% 1/16W
R4144 1-218-974-11 METAL CHIP 56K 5% 1/16W
R4145 1-218-963-11 METAL CHIP 6.8K 5% 1/16W
R4146 1-218-953-11 METAL CHIP 1K 5% 1/16W
R4147 1-218-977-11 METAL CHIP 100K 5% 1/16W
R4148 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4149 1-218-965-11 METAL CHIP 10K 5% 1/16W
R4150 1-218-977-11 METAL CHIP 100K 5% 1/16W
R4174 1-216-864-11 SHORT CHIP 0
R4175 1-216-864-11 SHORT CHIP 0
*************************************************************
MISCELLANEOUS
**************
0 AC1 1-821-082-21 INLET, AC 2P (~ AC IN)
0 F001 1-532-505-33 FUSE (T 5 AL/250 V)
0 F901 1-532-503-33 FUSE (T 1.6 AL/250 V)
FC1 1-500-386-11 FILTER, CLAMP (FERRITE CORE)
FC2 1-500-386-11 FILTER, CLAMP (FERRITE CORE)
FC3 1-500-386-11 FILTER, CLAMP (FERRITE CORE)
FC4 1-500-082-11 CLAMP, SLEEVE FERRITE
FC6 1-469-829-11 CORE, FERRITE
FC7 1-469-829-11 CORE, FERRITE
FC8 1-500-082-11 CLAMP, SLEEVE FERRITE
FC9 1-500-082-11 CLAMP, SLEEVE FERRITE
FFC1 1-828-002-61 WIRE (FLAT TYPE) (17 CORE)
FFC2 1-828-307-61 WIRE (FLAT TYPE) (9 CORE)
FFC3 1-846-332-11 CABLE, FLEXIBLE FLAT (51 pin)
FFC4 1-828-334-61 WIRE (FLAT TYPE) (13 CORE)
HDC1 1-846-354-11 CABLE, HDMI
IC500 6-702-390-01 TRANSISTOR MN2488-OPY-MK
IC501 6-702-391-01 TRANSISTOR MP1620-OPY-MK
IC503 6-702-390-01 TRANSISTOR MN2488-OPY-MK
IC504 6-702-391-01 TRANSISTOR MP1620-OPY-MK
IC505 6-702-390-01 TRANSISTOR MN2488-OPY-MK
IC506 6-702-391-01 TRANSISTOR MP1620-OPY-MK
IC508 6-702-390-01 TRANSISTOR MN2488-OPY-MK
IC509 6-702-391-01 TRANSISTOR MP1620-OPY-MK
IC510 6-702-390-01 TRANSISTOR MN2488-OPY-MK
IC511 6-702-391-01 TRANSISTOR MP1620-OPY-MK
IC513 6-702-390-01 TRANSISTOR MN2488-OPY-MK
IC514 6-702-391-01 TRANSISTOR MP1620-OPY-MK
IC515 6-702-390-01 TRANSISTOR MN2488-OPY-MK
IC516 6-702-391-01 TRANSISTOR MP1620-OPY-MK
0 M1 1-787-931-11 DC FAN
0 T901 1-697-178-11 POWER TRANSFORMER
TU1 A-1846-564-A TUNER1AMF ASSY (FM/AM TUNER UNIT)
*************************************************************
ACCESSORIES
************
1-458-399-11 USB WIRELESS ADAPTER (UWA-C4Z)
(Lighting Control Adapter)
1-490-454-11 REMOTE COMMANDER (RM-AAU155)
(Remote control)
1-542-830-11 MEASUREMENT MIC (MONO)
(Optimizer microphone ECM-AC2)
1-754-741-11 LOOP ANTENNA (AM loop antenna (aerial))
1-759-586-22 CONTROLLER, VIDEO (AV MOUSE) (IR blaster)
(1 piece)
1-793-184-41 CONNECTOR (F TYPE ADAPTOR)
(FM wire antenna (aerial))
0 1-839-698-11 CORD, POWER (AC power cord (mains lead))
4-429-113-11 MANUAL, INSTRUCTION (ENGLISH)
USB
Note: Wires (fl at type) (Ref. No. FFC4) for service is straight.
Please bend it referring go “HOW TO BEND WIRE
(FLAT TYPE)” on page 35 when you install it in the unit.
