Version 5.2 Sourcefire 3D System Installation Guide 169
Hardware Specifications
Sourcefire 7000 Series Devices
Chapter 6
The following table describes the features that appear on the rear of the
appliance.
The 10/100/1000 management interface is located on the rear of the appliance.
The following table describes the LEDs associated with the management
interface.
3D7115 and 3D7125 System Components: Rear View
FEATURES DESCRIPTION
VGA port
USB port
Allows you to attach a monitor, keyboard, and mouse to the device to
establish a direct workstation-to-appliance connection.
10/100/1000 Ethernet
management interface
Provides for an out-of-band management network connection. The
management interface is used for maintenance and configuration
purposed only and is not intended to carry service traffic.
System ID LED Helps identify a system installed in a high-density rack with other similar
systems. The blue light indicates that the ID button is pressed.
Grounding studs Allows you to connect the appliance to the Common Bonding Network.
See the Power Requirements for Sourcefire Devices on page 240for
more information.
Redundant power supplies Provides power to the device through an AC power source.
Power supply LEDs Indicates the status of the power supply. See 3D7115 and 3D7125
Power Supply LED on page 170.
3D7115 and 3D7125 Management Interface LEDs
LED DESCRIPTION
Left (activity) Indicates activity on the port:
• A blinking light indicates activity.
• No light indicates there is no activity.
Right (link) Indicates whether the link is up:
• A light indicates the link is up.
• No light indicates there is no link.
