Source fire Sourcefire 3D System - 8000 Series Chassis Front View

Version 5.2 Sourcefire 3D System Installation Guide 173
Hardware Specifications
Sourcefire 8000 Series Devices
Chapter 6
See the following sections for more information:
• 8000 Series Chassis Front View on page 173
• 8000 Series Chassis Rear View on page 178
• 8000 Series Physical and Environmental Parameters on page 181
• 8000 Series Modules on page 185
8000 Series Chassis Front View
The 8000 Series chassis can be in the 81xx Family or 82xx Family. See Sourcefire
Series 3 Information on page 232 for safety considerations for 81xx Family and
82xx Family appliances.
81xx Family Chassis Front View
The front view of the chassis contains the LCD panel, front panel, and three
module slots.
81xx Family (Chassis: CHAS-1U-AC/DC) Front View
82xx Family Chassis Front View
The front view of the chassis contains the LCD panel, front panel, and seven
module slots.
82xx Family (Chassis: CHAS-2U-AC/DC) Front View
Module Slots
LCD Panel
Front Panel
1
2
3
Front Panel
LCD Panel
Module Slots
4
5
7
1
2
3
6
