Source fire Sourcefire 3D System - 8000 Series Physical and Environmental Parameters

Version 5.2 Sourcefire 3D System Installation Guide 181
Hardware Specifications
Sourcefire 8000 Series Devices
Chapter 6
8000 Series Physical and Environmental Parameters
The following table describes the physical attributes and environmental
parameters for 81xx Family devices.
8 CTS Clear to send 8
9 No connection
8000 Series RJ45 to DB-9 Adapter Pin-Out (Continued)
DB-9 PIN SIGNAL DESCRIPTION RJ45 PIN
81xx Family Physical and Environmental Parameters
PARAMETER DESCRIPTION
Form factor 1U
Dimensions
(D x W x H)
28.7” x 17.2” x 1.73” (72.8 cm x 43.3 cm x 4.4 cm)
Weight
maximum installed
43.5 lbs (19.8 kg)
Copper 1000BASE-T
configurable bypass
NetMod
Quad-port Gigabit copper ethernet configurable bypass interfaces in a paired
configuration
Cable and distance: Cat5E at 50 m
Fiber 10GBASE
configurable bypass
MMSR or SMLR
NetMod
Dual-port fiber configurable bypass interfaces with LC connectors
Cable and distance:
LR is single-mode at 5000 m (available)
SR is multimode fiber (850 nm) at 550 m (standard)
Fiber 1000BASE-SX
configurable bypass
NetMod
Quad-port fiber configurable bypass interfaces 1000BASE-SX with LC
connectors
Cable and distance: SX is multimode fiber (850 nm) at 550 m (standard)
Copper 1000BASE-T
non-bypass NetMod
Quad-port Gigabit copper ethernet non-bypass interfaces in a paired
configuration
Cable and distance: Cat5E at 50 m
Fiber 10GBASE
non-bypass
MMSR or SMLR
NetMod
Quad-port fiber non-bypass interfaces with LC connectors
Cable and distance:
LR is single-mode at 5000 m (available)
SR is multimode fiber (850 nm) at 550 m (standard)
Fiber 1000BASE-SX
non-bypass NetMod
Quad-port fiber non-bypass interfaces 1000BASE-SX with LC connectors
Cable and distance: SX is multimode fiber (850 nm) at 550 m (standard)
