Hardware Specifications
Sourcefire 8000 Series Devices
Chapter 6
Use the 1000BASE-SX NetMod Optical Parameters table to understand the
optical specifications of the fiber interfaces.
Dual-Port 10GBASE (MMSR or SMLR) Fiber Configurable Bypass NetMod
The dual-port 10GBASE (MMSR or SMLR) fiber configurable bypass NetMod
contains two fiber ports and link, activity, and bypass LEDs.
1000BASE-SX NetMod Optical Parameters
PARAMETER 1000BASE-SX
Optical connectors LC duplex
Bit rate 1000Mbps
Baud rate/encoding/tolerance 1250Mbps / 8b/10b encoding
Optical interface Multimode
Operating distances 200 m (656 ft) for 62.5 μm/125 μm fiber
500 m (1640 ft) for 50 μm/125 μm fiber
Transmitter wavelength 770-860 nm (850 nm typical)
Maximum average launch power 0 dBm
Minimum average launch power -9.5 dBm
Maximum average power at
receiver
0 dBm
Receiver sensitivity -17 dBm
Link LED
Ports
Bypass LEDActivity LED
