Version 5.2 Sourcefire 3D System Installation Guide 195
Hardware Specifications
Sourcefire 8000 Series Devices
Chapter 6
Quad-Port 10GBASE (MMSR or SMLR) Fiber Non-Bypass NetMod
The quad-port 10GBASE (MMSR or SMLR) fiber non-bypass NetMod contains
four fiber ports, and link and activity LEDs.
WARNING! The quad-port 10GBASE non-bypass NetMod contains
non-removable SFPs. Any attempt to remove the SFP can damage the module.
Use the Fiber Link/Activity LEDs table to understand the link and activity LEDs on
fiber interfaces.
Transmitter wavelength 770-860 nm (850 nm typical)
Maximum average launch power 0 dBm
Minimum average launch power -9.5 dBm
Maximum average power at
receiver
0 dBm
Receiver sensitivity -17 dBm
1000BASE-SX NetMod Optical Parameters (Continued)
PARAMETER 1000BASE-SX
Link LED
Ports
Activity LED
Fiber Link/Activity LEDs
STATUS DESCRIPTION
Top For an inline or passive interface: the light flashes when the
interface has activity. If dark, there is no activity.
Bottom For an inline interface: the light is on when the interface has
link. If dark, there is no link.
For a passive interface: the light is always on.
