Description of the BMK-8i ACCU stud welding device
Operating Instructions Soyer Bolzenschweißtechnik 31
7.4 Technical data of the BMK-8i ACCU stud welding device
Stud welding device:
Designation BMK-8i ACCU stud welding device
Welding procedure Drawn arc stud welding (DS)
Standard gun
PH-9 SRM
12
stud welding gun
and PH-9 SRM
12
+G stud welding gun
Welding area SOYER® threaded stud, from M3 - M8
(preferably M6 and M8) HZ-1 and MF types
or Ø 2 - 4 mm nails (optional)
Power source Inverter technology
Welding current 100 - 300 A
Welding time 10 to 500 ms
Welding sequence Ø 6 mm up to 6 studs/min
Ø 8 mm up to 3 studs/min
Mains connection Wide-range power supply 110 - 230 volt,
50/60 Hz
16AT or 16AC characteristics
Electric charging capacity 130 VA
Open-circuit voltage < 30 V / DC (direct current voltage)
Protection class IP 21
Shielding gas connection max. 12 l/min
Dimensions 190 x 300 x 450 mm (w x h x d)
Weight approx. 8 kg
Colour Blue
Subject to technical changes
