Description of the PH-3N SRM stud welding gun
54 Operating Instructions Soyer Bolzenschweißtechnik
11.1 Technical data of the PH-3N SRM stud welding gun
(*) With adapter plug, see technical data on the stud welding device.
i
The PH-3N SRM stud welding gun may only be operated with the stud
welding devices specified in the technical data.
Technical data of the PH-3N SRM stud welding gun
Designation PH-3N SRM stud welding gun
Item no. P02245
Welding procedure • Drawn arc stud welding
• SRM® welding procedure
Stud diameter M3 - M12 (depending on the stud welding device)
Stud chuck SRM® stud chuck and SRM® nut holder
Stud length Standard up to 60 mm, special lengths on request
and possible with optional accessory
Stud welding devices The gun is approved for operation on the following
SOYER® stud welding devices:
• BMK-8i, BMK-8i ACCU, BMK-10i (*)
• BMK-12i (*)
• BMK-16i
Weight 4.6 kg
Subject to technical changes
