Welding operation
72 Operating Instructions Soyer Bolzenschweißtechnik
14. Welding operation
In the following, it is described how weldings are carried out and how possible
welding errors can be avoided.
14.1 Carrying out welding
In the following, it is described how weldings are carried out with a stud welding
gun.
DA NGER
!
Danger from incorrect operation
During stud welding, incorrect operation of the devices may cause many
dangers.
• Before using the stud welding device, see chapter “2. Important safety
instructions” on page 10.
• If you have any problems understanding the operating instructions, contact
the manufacturer, Soyer.
• Before each use, check that the devices and the cables/lines with the
plugs are undamaged.
Carrying out welding
Step 1: Before welding, see chapter “2. Important safety instructions” on
page 10.
Step 2: Connect the gun to the stud welding device (see chapter “12.2
Connection of the stud welding device and the stud welding
guns” on page 59).
Check if a connection adapter may be required.
Step 3: Insert the appropriate stud chuck and a welding stud (see chap-
ter “8. Description of the SRM® stud chuck” on page 36).
Only use SOYER® welding studs.
Step 4: To check the battery charging status, press the release button of
the welding gun.
Step 5: Check the welding parameters (see chapter “13. Settings” on
page 64).
