Description of the PH-9 SRM
12
stud welding gun
Operating Instructions Soyer Bolzenschweißtechnik 39
The height of lift is adjusted using the dial on the gun
(see Figure 5: "PH-9 SRM
12
stud welding gun").
The PH-9 SRM
12
stud welding gun has a gas insert for each stud chuck diameter:
• M6: F06738
• M8: F06739
• M10: F06740
• M12: F06741
The gas insert is used to optimise the gas flow and to insulate the stud chuck
against the shielding gas shroud.
9.1 Technical data of the PH-9 SRM
12
stud welding gun
i
The PH-9 SRM
12
stud welding gun may only be operated with the stud
welding devices specified in the technical data.
Technical data of the PH-9 SRM
12
stud welding gun
Designation
PH-9 SRM
12
stud welding gun
Item no. P02276
Welding procedure • Drawn arc stud welding
• SRM® welding procedure
Stud diameter M3 - M12 (depending on the stud welding device)
Stud chuck SRM® stud chuck
Stud length Standard up to 60 mm, special lengths on request
and possible with optional accessory
Stud welding devices The gun is approved for operation on the following
SOYER® stud welding devices:
• BMK-8i, BMK-8i ACCU, BMK-10i
• BMK-12i
• BMK-16i when using the following adapters:
Control cable adapter: F06770/FA
Earth cable adapter: F06771/FA
Gas adapter: F06772/FA
Weight 3.7 kg
Subject to technical changes
