Programming Your Application 6-35
605C Frequency Inverter
JOG
This block holds all the parameters that
concern the Jog functionality on the
Inverter.
Functional Description
The JOG function block is used to configure the action of the Inverter when used in jog mode.
The various operating modes are described in more detail in Chapter 4: “Operating the Inverter”
- The Start/Stop Mode Explained.
MMI Menu Map
1
SETUP PARAMETERS
2
FUNCTION BLOCKS
3
SEQ & REF
4
JOG
JOG SETPOINT
JOG ACCEL RATE
JOG DECEL RATE
JOG
10.00 % – [246] SETPOINT
–
1.0 s
–
[261] ACCEL RATE
–
1.0 s
–
[262] DECEL RATE
–
Parameter Descriptions
SETPOINT
Range: 0.00 to 100.00 %
The setpoint is the target reference that the Inverter will ramp to. Direction is taken from the
current mode, (LOCAL or REMOTE).
ACCEL RATE
Range: 0.0 to 600.0 s
The jog mode acceleration rate.
DECEL RATE
Range: 0.0 to 600.0 s
The jog mode deceleration rate.
