SSD 605C - Specification Table: Tag Number Order

10-2 Parameter Specification
605C Frequency Inverter
Specification Table: Tag Number Order
Tag (MMI) Name Block Type Range ID Notes
1 LANGUAGE OP STATION ENUM 0 : ENGLISH
1 : DEUTSCH
2 : FRANCAIS
3 : ESPANOL
01
3 VIEW LEVEL OP STATION ENUM 0 : OPERATOR
1 : BASIC
2 : ADVANCED
3 : RESERVED
4 : ENGINEERING
03
4 ACTIVE TRIPS TRIPS STATUS WORD 0000 to FFFF 04 Output
5 TRIP WARNINGS TRIPS STATUS WORD 0000 to FFFF 05 Output
6 FIRST TRIP TRIPS STATUS ENUM 0 : NO TRIP
1 : LINK OVERVOLTS
2 : LINK UNDERVOLT
3 : OVERCURRENT
4 : HEATSINK TEMP
5 : EXTERNAL TRIP
6 : INPUT 1 BREAK
7 : INPUT 2 BREAK
8 : MOTOR STALLED
9 : I*T TRIP
10 : BRAKE RESISTOR
11 : BRAKE SWITCH
12 : OP STATION
13 : LOST COMMS
14 :
15 :
16 :
17 : MOTOR TEMP
18 : CURRENT LIMIT
19 : SHORT CIRCUIT
20 : 24V FAILURE
21 : LOW SPEED I
22 : PHASE FAIL
06 Output
7 ENTER PASSWORD PASSWORD WORD 0000 to FFFF 07 1, 5, 6
8 CHANGE PASSWORD PASSWORD WORD 0000 to FFFF 08 5, 6
12 AIN 1 BREAK ENBL ANALOG INPUT 1 BOOL FALSE / TRUE 0c
13 AIN 1 TYPE ANALOG INPUT 1 ENUM 0 : 0..+10 V
1 : +2..+10 V
2 : 0..+5 V
3 : +1..+5 V
4 : -10..+10 V
5 : 0..20 mA
6 : 4..20 mA
7 : 20..4 mA
8 : 20..0 mA
0d 7
14 AIN 1 SCALE ANALOG INPUT 1 INT -300.00 to 300.00 % 0e
15 AIN 1 OFFSET ANALOG INPUT 1 INT -300.00 to 300.00 % 0f
16 AIN 1 VALUE ANALOG INPUT 1 INT xxx.xx % 0g Output
17 AIN 1 BREAK VAL ANALOG INPUT 1 INT -300.00 to 300.00 % 0h
18 AIN 1 BREAK ANALOG INPUT 1 BOOL FALSE / TRUE 0i Output
21 AIN 2 BREAK ENBL ANALOG INPUT 2 BOOL FALSE / TRUE 0l
22 AIN 2 TYPE ANALOG INPUT 2 ENUM Same as tag 13 0m 7
23 AIN 2 SCALE ANALOG INPUT 2 INT -300.00 to 300.00 % 0n
24 AIN 2 OFFSET ANALOG INPUT 2 INT -300.00 to 300.00 % 0o
25 AIN 2 VALUE ANALOG INPUT 2 INT xxx.xx % 0p Output
26 AIN 2 BREAK VAL ANALOG INPUT 2 INT -300.00 to 300.00 % 0q
27 AIN 2 BREAK ANALOG INPUT 2 BOOL FALSE / TRUE 0r Output
