SSD 605C - System Port (P3)

Programming Your Application 6-65
605C Frequency Inverter
SYSTEM PORT (P3)
The unisolated RS232 programming port
allows for connection to the Operator
Station, or to a personal computer for drive
configuration and storage of parameters.
The parameters below are used to identify
the Inverter to the controlling software.
The port uses the SSD Drives standard EI BISYNCH ASCII protocol.
Functional Description
The unit will always respond to GID = 0 and UID = 0, as this is the “broadcast” address used by
the Operator Station.
Note: The Technology Option uses a different port and address. It does not respond to the
“broadcast” address.
SYSTEM PORT (P3)
0 – [102] GROUP ID (GID)
–
0
–
[103] UNIT ID (UID)
–
MMI Menu Map
1
SETUP PARAMETERS
2
FUNCTION BLOCKS
3
SERIAL LINKS
4
SYSTEM PORT (P3)
GROUP ID (GID)
UNIT ID (UID)
Parameter Descriptions
GROUP ID (GID)
Range: 0 to 9
The SSD Drives protocol group identity address.
UNIT ID (UID)
Range: 0 to 15
The SSD Drives protocol unit identity address
