11-6 Technical Specifications
605C Frequency Inverter
Control Terminals
Terminal
No.
Block
No.
Name Range Description
TB1 : ANALOG I/O TERMINAL BLOCK
This is a 10-way connector carrying all customer analog I/O.
1 TB1-1 AIN1 (SPEED)
0-10V, ±10V,
0-20mA, 4-20mA
Configurable analog input
Default function = Speed Setpoint
2 TB1-2 AIN2 (TRIM)
0-10V, ±10V,
0-20mA, 4-20mA
Configurable analog input
Default function = Speed Trim
3 TB1-3 AIN3 0-20mA, 4-20mA Configurable analog input
4 TB1-4 0V 0V reference for analog i/o
5 TB1-5 AIN4 0-10V Configurable analog input
6 TB1-6 AOUT1 (RAMP) 0-10V,
0-20mA, 4-20mA
Configurable analog output
Default function = Ramp Output
7 TB1-7 AOUT2
±10V
Configurable analog output
Default function = Ramp Output
8 TB1-8 +10V REF 10V 10V reference for analog i/o
Load 5mA maximum
9 TB1-9 0V 0V 0V reference for digital i/o
10 TB1-10 -10V REF -10V -10V reference for analog i/o
Load 5mA maximum
TB3 : DIGITAL INPUT TERMINAL BLOCK
This is a 10-way connector carrying all digital inputs.
11 TB3-1 +24VC Customer +24V (max load 150mA)
12 TB3-2 0V All inputs below 24V=high , 0V=low
13 TB3-3 DIN1 (RUN) 0-24V Configurable digital input
Default function = RUN
0V = Stop, 24V = Run
14 TB3-4 DIN2 (TRIP RESET) 0-24V Default function = Trip Reset
15 TB3-5 DIN3 (DIR) 0-24V Configurable digital input
Default function = DIRECTION
24V = Reverse, 0V = Forward
16 TB3-6 DIN4 (EXT TRIP) 0-24V Configurable digital input
Default function = EXTERNAL TRIP (active low)
24V = No Trip, 0V = Trip
17 TB3-7 DIN 5 (JOG) 0-24V Configurable digital input
Default function = JOG
24V = Jog, 0V = Stop
18 TB3-8 DIN6 0-24V
Default function: NON-USER DEFINED
19 TB3-9 DIN7 0-24V
Default function: NON-USER DEFINED
20 TB3-10 DIN8 0-24V
Default function: NON-USER DEFINED
TB4 : RELAY OUTPUT TERMINAL BLOCK
These relay ouputs are volt-free, normally-open contacts rated to 250V,
3A with resistive load. Connection is by a 6-way spring clamp connector.
21
22
TB4 DOUT1_A
DOUT1_B
normally-open
relay contacts
Default Function DOUT1 closed = Healthy
23
24
TB4 DOUT2_A
DOUT2_B
normally-open
relay contacts
Default Function DOUT2 closed = Running
25
26
TB4 DOUT3_A
DOUT3_B
normally-open
relay contacts
Default Function NON-USER DEFINED
