Technical Specifications 11-7
605C Frequency Inverter
Analog Inputs/Outputs
Inputs
Output
Range
0-10V, ±10V, 0-20mA or 4-20mA set by I/O
configuration switch.
Refer to Chapter 6: “Programming Your
Application” - ANALOG INPUT for switch
setting details.
0-10V, 0-20mA or 4-20mA set by I/O
configuration switch.
Refer to Chapter 6: “Programming Your
Application” - ANALOG OUTPUT for switch setting
details.
Impedance
Voltage range = 94kΩ
Current range = 220Ω
Voltage range = 100Ω
Current range = 100Ω
Resolution 10 bits (1 in 1024) 8 bits (1 in 256)
Sample Rate 20ms
Digital Inputs
Range -30V dc minimum 24V dc nominal +30V dc maximum
Threshold 6V dc minimum 12V dc typical 18V dc maximum
Input Impedance
47kΩ
Sample Rate 20ms
Digital Outputs
These are volt-free relay contacts.
Maximum Voltage 230V ac
Maximum Current 3A resistive load
