SSD 605C - Electrical Ratings

Technical Specifications 11-3
605C Frequency Inverter
Electrical Ratings
Motor power, output current and input current must not be exceeded under steady state
operating conditions. Also see 605C Model Recognition, page 11-1.
Local wiring regulations always take precedence.
* European wire sizes (mm²) are based on EN60204-1 (1993) for PVC single-core cable
bunched or in trunking given a 70ºC maximum conductor temperature under normal conditions
in a 45ºC ambient for Constant Torque and a 40ºC ambient for Quadratic Torque.
 North American wire sizes (AWG) are based on NEC/NFPA-70 for ampacities of
thermoplastic-insulated (75ºC) copper conductors assuming not more than three current-
carrying conductors in raceway or cable, based on ambient temperature of 30ºC. The wire sizes
allow for an ampacity of 125% of the rated input and output amperes for motor branch-circuit
conductors as specified in NEC/NFPA-70.
400V Build Variant: 380-460V ±10%, 45-65Hz
For UL Listed products rated at 20Hp a supply voltage of 460V is required
◆=Higher current ratings applicable to non UL applications
CONSTANT TORQUE (Output Overload Motoring 150% for 60s)
Model Recognition
Product Code
Motor
Power
(kW/hp)
Output
Current
(A)
Wire Size
*
AWG (mm²)
Input
Current
(A)
Wire Size
*
AWG (mm²)
Input
Fuse
Rating
(A)
Maximum
Power Loss
(W)
Maximum
Switching
Frequency
(kHz)
605C/0055/400/.. 5.5/7.5 12 14 (1.5) 15 12 (2.5) 20 220 6
605C/0075/400/.. 7.5/10 16 12 (2.5) 22 10 (4) 32 260 6
605C/0110/400/.. 11/15 23 10 (6) 28 8 (6) 32 330 6
QUADRATIC TORQUE (Output Overload Motoring 110% for 10s)
Model Recognition
Product Code
Motor
Power
(kW/hp)
Output
Current
(A)
Wire Size
*
AWG (mm²)
Input
Current
(A)
Wire Size
*
AWG (mm²)
Input
Fuse
Rating
(A)
Maximum
Power Loss
(W)
Maximum
Switching
Frequency
(kHz)
605C/0055/400/.. 7.5/10 16 12 (2.5) 20 10 (4) 32 270 3
605C/0075/400/.. 11/15 23 10 (4) 28 8 (6) 32 350 3
605C/0110/400/.. 15/20
27 (
◆31)
8 (6)
32 (◆35)
8 (10) 40 450 3
500V Build Variant: 500V ±10%, 45-65Hz
500V unit full ratings are only available at 500V.
The unit can be operated at between 380-500V with reduced power output below 500V
CONSTANT TORQUE (Output Overload Motoring 150% for 60s)
Model Recognition
Product Code
Motor
Power
(kW/hp)
Output
Current
(A)
Wire Size
(mm²)
Input
Current
(A)
Wire Size
(mm²)
Input
Fuse
Rating
(A)
Maximum
Power Loss
(W)
Maximum
Switching
Frequency
(kHz)
605C/0055/500/.. 5.5/7.5 10 1.5 14 2.5 20 220 6
605C/0075/500/.. 7.5/10 12.5 2.5 22 4 32 260 6
605C/0110/500/.. 11/15 18 4 26 6 32 330 6
QUADRATIC TORQUE (Output Overload Motoring 110% for 10s)
Model Recognition
Product Code
Motor
Power
(kW/hp)
Output
Current
(A)
Wire Size
(mm²)
Input
Current
(A)
Wire Size
(mm²)
Input
Fuse
Rating
(A)
Maximum
Power Loss
(W)
Maximum
Switching
Frequency
(kHz)
605C/0055/500/.. 7.5/10 12.5 1.5 20 4 32 270 3
605C/0075/500/.. 11/15 18 2.5 26 6 32 350 3
605C/0110/500/.. 15/20 24 4 32 10 40 450 3
