SSD 605C - Multiplexer

6-42 Programming Your Application
605C Frequency Inverter
MULTIPLEXER
This block collects together 16 Boolean
input values into a single word.
This may be used to set and clear individual
bits within a word such as the TRIGGERS
1 word for the AUTO RESTART function
block.
MMI Menu Map
1
SETUP PARAMETERS
2
FUNCTION BLOCKS
3
MISCELLANEOUS
4
MULTIPLEXER
INPUT 0
INPUT 1
INPUT 2
INPUT 3
INPUT 4
INPUT 5
INPUT 6
INPUT 7
INPUT 8
INPUT 9
INPUT 10
INPUT 11
INPUT 12
INPUT 13
INPUT 14
INPUT 15
OUTPUT
MULTIPLEXER
OUTPUT [598]
–
0000
FALSE – [641] INPUT 0
–
FALSE
–
[642] INPUT 1
–
FALSE
–
[643] INPUT 2
–
FALSE
–
[644] INPUT 3
–
FALSE
–
[645] INPUT 4
–
FALSE
–
[646] INPUT 5
–
FALSE
–
[647] INPUT 6
–
FALSE
–
[648] INPUT 7
–
FALSE
–
[649] INPUT 8
–
FALSE
–
[650] INPUT 9
–
FALSE
–
[651] INPUT 10
–
FALSE
–
[652] INPUT 11
–
FALSE
–
[653] INPUT 12
–
FALSE
–
[654] INPUT 13
–
FALSE
–
[655] INPUT 14
–
FALSE
–
[656] INPUT 15
–
Parameter Descriptions
INPUT 0 TO INPUT 15
Range: FALSE / TRUE
The Boolean inputs to be assembled into a single word.
OUTPUT
Range: 0000 to FFFF
The resulting word.
