6-80 Programming Your Application
605C Frequency Inverter
VECTOR FLUXING
This function block allows the user to both
enable the sensorless vector fluxing mode
and enter details of the motor to be
controlled. Once enabled, vector fluxing
automatically replaces the conventional V
to F fluxing and enables slip
compensation.
Refer to Chapter 4: “Operating the
Inverter” - Setting-up the Inverter,
for a description of the vector fluxing of
the Inverter.
MMI Menu Map
1
SETUP PARAMETERS
2
FUNCTION BLOCKS
3
MOTOR CONTROL
4
VECTOR FLUXING
VECTOR ENABLE
MOTOR CONNECTION
STATOR RES
LEAKAGE INDUC
MUTUAL INDUC
SUPPLY VOLTAGE
VECTOR FLUXING
SUPPLY VOLTAGE [596]
400.0 V
FALSE [118] ENABLE
** STAR
[124] MOTOR CONNECTION
** 4.95 Ohm
[119] STATOR RES
** 52.5 mH
[120] LEAKAGE INDUC
** 472.6 mH
[121] MUTUAL INDUC
Parameter Descriptions
ENABLE
Range: FALSE / TRUE
This parameter enables sensorless vector Inverter operation.
Note: Cannot be enabled if Quadratic Torque mode is selected.
MOTOR CONNECTION
Range: Enumerated - see below
This parameter is used to indicate how the motor is connected to the Inverter. The choice for this
parameter is:
Enumerated Value : Motor Connection
0 : DELTA
1 : STAR
STATOR RES
Range: 0.00 to 100.00 Ohm
This parameter is used to program the value of the motor per-phase stator resistance.
LEAKAGE INDUC
Range: 0.0 to 1000.0 mH
This parameter is used to program the value of the motor per-phase stator leakage inductance.
MUTUAL INDUC
Range: 0.0 to 1000.0 mH
This parameter is used to program the value of the motor per-phase stator mutual (magnetising)
inductance.
SUPPLY VOLTAGE
Range: xxxx.x V
This parameter indicates the line to line rms supply voltage to the Inverter.
