SSD 605C - Custom Screen

Programming Your Application 6-21
605C Frequency Inverter
CUSTOM SCREEN
This function block provides a custom screen for displaying any parameter. It allows you to
enter any 16 character name for the parameter and to display and enter in a convenient and
recognisable form.
MMI Menu Map
1
SETUP PARAMETERS
2
FUNCTION BLOCKS
3
MENUS
4
CUSTOM SCREEN 1
4
CUSTOM SCREEN 2
TAG NO
NAME
UNITS
DECIMAL PLACE
FORMULA
COEFFICIENT A
COEFFICIENT B
COEFFICIENT C
HIGH LIMIT
LOW LIMIT
Parameter Descriptions
TAG NO
Range: 0 to 787
Enter the tag number of the parameter to be displayed
NAME
Range: 16 characters
A 16 character label that is displayed as the parameter name.
UNITS
Range: 5 characters
A 5 character label that is displayed as the parameter units.
DECIMAL PLACE
Range: Enumerated - see below
Select the position of the decimal point. Note that “_” indicates a character that will not
display on the Operator Station.
Enumerated Value : Decimal Place
0 : XXXXX.
1 : XXXX.X
2 : XXX.XX
3 : XX.XXX
4 : X.XXXX
5 : XXXX._
6 : XXX.X_
7 : XX.XX_
8 : X.XXX_
CUSTOM SCREEN 1
0 – [ 74] TAG NO
–
–
[324] NAME
–
–
[323] UNITS
–
XXXXX.
–
[334] DECIMAL PLACE
–
A/B * X + C
–
[125] FORMULA
–
100
–
[321] COEFFICIENT A
–
100
–
[ 44] COEFFICIENT B
–
0
–
[322] COEFFICIENT C
–
30000
–
[101] HIGH LIMIT
–
-30000
–
[ 53] LOW LIMIT
–
CUSTOM SCREEN 2
0 – [371] TAG NO
–
–
[378] NAME
–
–
[377] UNITS
–
XXXXX.
–
[379] DECIMAL PLACE
–
A/B * X + C
–
[676] FORMULA
–
100
–
[375] COEFFICIENT A
–
100
–
[673] COEFFICIENT B
–
0
–
[376] COEFFICIENT C
–
30000
–
[674] HIGH LIMIT
–
-30000
–
[675] LOW LIMIT
–
FORMULA
Range: Enumerated - see below
Enumerated Value : Formula
0 : A/B * X + C
1 : A/B * (X+C)
2 : A/(B * X) + C
3 : A/(B * (X+C))
