Parameter Specification 10-19
605C Frequency Inverter
Product-Related Default Values
All examples given in this book are based on a UK, 400V, 50Hz, 7.5kW Inverter. The
parameters shown below have values that can vary with build/configuration.
Language Dependant Defaults
These parameters (marked with “*” in function block descriptions and macro diagrams) are set
to a value depending on the Language portion of the Product Code.
Tag English (UK) German (GR) French (FR) Spanish (SP)
LANGUAGE 1 ENGLISH DEUTSCH FRANCAIS ESPANOL
MAX SPEED 57 50.0Hz 50.0Hz 50.0Hz 50.0Hz
BASE FREQUENCY 106 50.0Hz 50.0Hz 50.0Hz 50.0Hz
CONFIGURATION ID 339 AC MOTOR DRIVE AC MOTOR DRIVE CONV FREQUENCE VARIADOR ALTERNA
Tag American (US) P 50Hz (P5) P 60Hz (P6)
LANGUAGE 1 ENGLISH { 0} { 0}
MAX SPEED 57 60.0Hz 50.0Hz 60.0Hz
BASE FREQUENCY 106 60.0Hz 50.0Hz 60.0Hz
CONFIGURATION ID 339 AC MOTOR DRIVE AC MOTOR DRIVE AC MOTOR DRIVE
