Technical Specifications 11-1
605C Frequency Inverter
11 TECHNICAL SPECIFICATIONS
605C Model Recognition
The 605C Inverter is produced in three power ratings, identified by the Product Code.
Each power rating is also available as a 400V or 500V build variant.
400V Build Variant: 380-460V Supply
Model Recognition CONSTANT TORQUE QUADRATIC TORQUE
Product Code
Refer to Chapter 2 for details
Motor Power
(kW/hp)
Motor Power
(kW/hp)
605C/0055/400/.. 5.5/7.5 7.5/10
605C/0075/400/.. 7.5/10 11/15
605C/0110/400/.. 11/15 15/20
500V Build Variant: 380-500V Supply
Model Recognition CONSTANT TORQUE QUADRATIC TORQUE
Product Code
Refer to Chapter 2 for details
Motor Power
(kW/hp)
Motor Power
(kW/hp)
605C/0055/500/.. 5.5/7.5 7.5/10
605C/0075/500/.. 7.5/10 11/15
605C/0110/500/.. 11/15 15/20
Environmental Details
Operating Temperature
Constant Torque
Quadratic Torque
Operating temperature is defined as the ambient temperature to the immediate
surround of the Inverter, when the Inverter and other equipment adjacent to it is
operating at worst case conditions.
0°C to 45°C (0°C to 40°C with top cover fitted), derate up to a maximum of 50°C
0°C to 40°C (0°C to 40°C with top cover fitted), derate up to a maximum of 50°C
Storage Temperature
-25°C to +55°C
Shipping Temperature
-25°C to +70 °C
Product Enclosure Rating Cubicle Mounted
(with top cover fitted)
IP40 - top cover surface (Europe)
IP20 - remainder of surfaces (Europe)
Cubicle Mounted
(without top cover fitted)
IP20
UL (c-UL) Open Type (North America/Canada)
Wall Mounted UL (c-UL) Type 1 (North America/Canada)
Altitude If >1000 metres above sea level, derate Motor Power rating by 1% per 100 metres
Humidity
Maximum 85% relative humidity at 40°C non-condensing
Atmosphere Non flammable, non corrosive and dust free
Climatic Conditions Class 3k3, as defined by EN50178 (1997)
Vibration Test Fc of EN60068-2-6
19Hz<=f<=57Hz sinusoidal 0.075mm amplitude
57Hz<=f<=150Hz sinusoidal 1g
10 sweep cycles per axis on each of three mutually perpendicular axis
Safety
Overvoltage Category Overvoltage Category III
Pollution Degree Pollution Degree 2
Europe When fitted inside a cubicle, or when wall-mounted and the top cover is firmly screwed
in position, this product conforms with the Low Voltage Directive 73/23/EEC with
amendment 93/68/EEC, Article 13 and Annex III using EN50178 (1997) to show
compliance.
North America/Canada Without the top cover fitted, complies with the requirements of UL508C as an open-
type drive. When the top cover is fitted, complies with the requirements of UL508C as
Type 1 Enclosed (for direct wall mounting applications) when specified with Product
Code Block 4 designation xx2x only.
