11-2 Technical Specifications
605C Frequency Inverter
Earthing/Safety Details
Earthing Permanent earthing is mandatory on all units.
Use a copper protective earth conductor 10mm² minimum cross-section, or install a second
conductor in parallel with the protective conductor to a separate protective earth terminal
The conductor itself must meet local requirements for a protective earth conductor
Input Supply Details
(TN) and (IT)
Units with single phase or 3 phase external filters are only suitable for use on earth referenced
supplies (TN).
Units without filters are suitable for earth (TN) or non-earth referenced (IT) supplies.
Prospective Short
Circuit Current (PSCC)
10kA maximum
Terminal Block Wire Sizes
Wire sizes should be chosen with respect to the operating conditions and your local National
Electrical Safety Installation Requirements.
Model Recognition
Product Code
Constant/Quadratic Power Terminals
(maximum wire size)
Control Terminals , including
Thermistor block on Power Board
(maximum acceptance for aperture)
605C/0055/400/.. 5.5kW/7.5kW 4mm² (12 AWG) 2.5mm² (14 AWG)
605C/0075/400/.. 7.5kW/11kW 10mm² (8 AWG) 2.5mm² (14 AWG)
605C/0110/400/.. 11kW/15kW 10mm² (8 AWG) 2.5mm² (14 AWG)
Earth Leakage Current >10mA (all models)
