Parameter Specification 10-3
605C Frequency Inverter
Tag (MMI) Name Block Type Range ID Notes
28 FLY SETPOINT FLY CATCHING INT xxx.xx % 0s Output
30 DIN 1 INVERT DIGITAL INPUT 1 BOOL FALSE / TRUE 0u
31 DIN 1 VALUE DIGITAL INPUT 1 BOOL FALSE / TRUE 0v Output
32 FLY SEARCH BOOST FLY CATCHING INT 0.00 to 100.00 % 0w 3
33 DIN 2 INVERT DIGITAL INPUT 2 BOOL FALSE / TRUE 0x
34 DIN 2 VALUE DIGITAL INPUT 2 BOOL FALSE / TRUE 0y Output
36 DIN 3 INVERT DIGITAL INPUT 3 BOOL FALSE / TRUE 10
37 DIN 3 VALUE DIGITAL INPUT 3 BOOL FALSE / TRUE 11 Output
39 DIN 4 INVERT DIGITAL INPUT 4 BOOL FALSE / TRUE 13
40 DIN 4 VALUE DIGITAL INPUT 4 BOOL FALSE / TRUE 14 Output
42 DIN 5 INVERT DIGITAL INPUT 5 BOOL FALSE / TRUE 16
43 DIN 5 VALUE DIGITAL INPUT 5 BOOL FALSE / TRUE 17 Output
44 COEFFICIENT B CUSTOM SCREEN 1 INT 1 to 30000 18
45 AOUT 1 VALUE ANALOG OUTPUT 1 INT -300.00 to 300.00 % 19
46 AOUT 1 SCALE ANALOG OUTPUT 1 INT -300.00 to 300.00 % 1a
47 AOUT 1 OFFSET ANALOG OUTPUT 1 INT -300.00 to 300.00 % 1b
48 AOUT 1 ABS ANALOG OUTPUT 1 BOOL FALSE / TRUE 1c
49 AOUT 1 TYPE ANALOG OUTPUT 1 ENUM 0 : 0..+10 V
1 : 0..20 mA
2 : 4..20 mA
1d 7
50 QUADRATIC TORQUE CURRENT FEEDBACK BOOL FALSE / TRUE 1e 5, 7
51 DOUT 1 INVERT DIGITAL OUTPUT 1 BOOL FALSE / TRUE 1f
52 DOUT 1 VALUE DIGITAL OUTPUT 1 BOOL FALSE / TRUE 1g
53 LOW LIMIT CUSTOM SCREEN 1 INT -30000 to 30000 1h
54 DOUT 2 INVERT DIGITAL OUTPUT 2 BOOL FALSE / TRUE 1i
55 DOUT 2 VALUE DIGITAL OUTPUT 2 BOOL FALSE / TRUE 1j
57 MAX SPEED SETPOINT SCALE INT 0.0 to 480.0 Hz 1l 7
58 SCALE INPUT SETPOINT SCALE INT -300.00 to 300.00 % 1m
59 SCALE OUTPUT SETPOINT SCALE INT xxx.xx %lf 1n Output
60 SLEW ENABLE SLEW RATE LIMIT BOOL FALSE / TRUE 1o
61 SLEW DECEL LIMIT SLEW RATE LIMIT INT 12.0 to 1200.0 Hz/s 1p
62 SLEW ACCEL LIMIT SLEW RATE LIMIT INT 12.0 to 1200.0 Hz/s 1q
64 FULL LOAD CALIB CURRENT FEEDBACK INT 0.0 to 1000.0 A 1s 3, 7
65 NO LOAD CALIB CURRENT FEEDBACK INT 0.0 to 1000.0 A 1t 3, 7
66 MOTOR CURRENT CURRENT FEEDBACK INT xxx.xh % (h) 1u Output
67 MOTOR CURRENT CURRENT FEEDBACK INT xxxx.x A 1v Output
68 I MAGNETISING CURRENT FEEDBACK INT xxx.xh % (h) 1w Output
69 I MAGNETISING CURRENT FEEDBACK INT xxxx.x A 1x Output
70 I TORQUE CURRENT FEEDBACK INT xxx.xh % (h) 1y Output
71 I TORQUE CURRENT FEEDBACK INT xxxx.x A 1z Output
72 LOAD CURRENT FEEDBACK INT xxx.xh % (h) 20 Output
73 FIELD CURRENT FEEDBACK INT xxx.xh % (h) 21 Output
74 TAG NO CUSTOM SCREEN 1 TAG 0 to 787 22
75 DC LINK VOLTS DYNAMIC BRAKING INT xxxx.x V 23 Output
77 BRAKE RESISTANCE DYNAMIC BRAKING INT 1 to 1000 Ohm 25 7
78 BRAKE POWER DYNAMIC BRAKING INT 0.1 to 510.0 kW 26 7
79 BRAKE 1S RATING DYNAMIC BRAKING INT 1 to 40 27 7
80 BRAKE ENABLE DYNAMIC BRAKING BOOL FALSE / TRUE 28
81 BRAKING DYNAMIC BRAKING BOOL FALSE / TRUE 29 Output
