10-4 Parameter Specification
605C Frequency Inverter
Tag (MMI) Name Block Type Range ID Notes
82 SLIP ENABLE SLIP COMP BOOL FALSE / TRUE 2a 7
83 NAMEPLATE RPM SLIP COMP INT 0 to 28800 n/min 2b 3, 7
84 MOTOR POLES SLIP COMP ENUM 0 : 2
1 : 4
2 : 6
3 : 8
4 : 10
5 : 12
2c 3, 7
85 SLIP MOTOR LIMIT SLIP COMP INT 0.0 to 600.0 n/min 2d 3
86 SLIP REGEN LIMIT SLIP COMP INT 0.0 to 600.0 n/min 2e 3
89 A DIN 1 INVERT ANALOG DIGIN 1 BOOL FALSE / TRUE 2h
90 A DIN 1 VALUE ANALOG DIGIN 1 BOOL FALSE / TRUE 2i Output
91 A DIN 1 LEVEL ANALOG DIGIN 1 INT 0.00 to 100.00 % 2j
92 A DIN 1 HYST ANALOG DIGIN 1 INT 0.00 to 50.00 % 2k
93 STARTUP SCREEN OPERATOR MENU INT 0 to 15 2l
94 A DIN 2 INVERT ANALOG DIGIN 2 BOOL FALSE / TRUE 2m
95 A DIN 2 VALUE ANALOG DIGIN 2 BOOL FALSE / TRUE 2n Output
96 A DIN 2 LEVEL ANALOG DIGIN 2 INT 0.00 to 100.00 % 2o
97 A DIN 2 HYST ANALOG DIGIN 2 INT 0.00 to 50.00 % 2p
98 RANDOM PATTERN PATTERN GEN BOOL FALSE / TRUE 2q 7
99 PATTERN GEN FREQ PATTERN GEN ENUM 0 : 3 kHz
1 : 6 kHz
2 : 9 kHz
2r 7
100 DEFLUX DELAY PATTERN GEN INT 0.1 to 10.0 s 2s 3
101 HIGH LIMIT CUSTOM SCREEN 1 INT -30000 to 30000 2t
102 GROUP ID (GID) SYSTEM PORT (P3) INT 0 to 9 2u
103 UNIT ID (UID) SYSTEM PORT (P3) INT 0 to 15 2v
104 V/F SHAPE FLUXING ENUM 0 : LINEAR LAW
1 : FAN LAW
2w 7
105 V/F SCALE FLUXING INT 0.00 to 100.00 % 2x 7
106 BASE FREQUENCY FLUXING INT 7.5 to 480.0 Hz 2y 3
107 FIXED BOOST FLUXING INT 0.00 to 25.00 % 2z 3
108 AUTO BOOST FLUXING INT 0.00 to 25.00 % 30 3
112 BASE VOLTS VOLTAGE CONTROL INT 0.00 to 115.47 % 34
113 LIMIT FREQUENCY FLUXING ENUM 0 : 120 Hz
1 : 240 Hz
2 : 480 Hz
35 7
115 OP DATABASE OP STATION BOOL FALSE / TRUE 37 Output
116 AUTO BACKUP OP STATION BOOL FALSE / TRUE 38
118 VECTOR ENABLE VECTOR FLUXING BOOL FALSE / TRUE 3a 7
119 STATOR RES VECTOR FLUXING INT 0.00 to 100.00 Ohm 3b 3, 7
120 LEAKAGE INDUC VECTOR FLUXING INT 0.0 to 1000.0 mH 3c 3, 7
121 MUTUAL INDUC VECTOR FLUXING INT 0.0 to 1000.0 mH 3d 3, 7
122 MOTOR VOLTS VOLTAGE CONTROL INT 198.0 to 550.0 V 3e 3
124 MOTOR
CONNECTION
VECTOR FLUXING ENUM 0 : DELTA
1 : STAR
3g 3, 7
125 FORMULA CUSTOM SCREEN 1 ENUM 0 : A/B * X + C
1 : A/B * (X+C)
2 : A/(B * X) + C
3 : A/(B * (X+C))
3h
126 FINAL STOP RATE STOP INT 12 to 4800 Hz/s 3i
127 ENABLED KEYS OP STATION WORD 0000 to FFFF 3j
128 STB ENABLE STABILISATION BOOL FALSE / TRUE 3k
