SSD 605C - Page 167

Parameter Specification 10-5
605C Frequency Inverter
Tag (MMI) Name Block Type Range ID Notes
130 INPUT A VALUE FUNC 1 INT -300.00 to 300.00 % 3m
131 INPUT B VALUE FUNC 1 INT -300.00 to 300.00 % 3n
132 INPUT C VALUE FUNC 1 INT -300.00 to 300.00 % 3o
133 OUTPUT VALUE FUNC 1 INT xxx.xx % 3p Output
134 TYPE VALUE FUNC 1 ENUM 0 : IF(C) -A
1 : ABS(A+B+C)
2 : SWITCH(A,B)
3 : (A*B)/C
4 : A+B+C
5 : A-B-C
6 : B<=A<=C
7 : A>B+/-C
8 : A>=B
9 : ABS(A)>B+/-C
10 : ABS(A)>=B
11 : A(1+B)
12 : IF(C) HOLD(A)
13 : BINARY DECODE
14 : ON DELAY
15 : OFF DELAY
16 : TIMER
17 : MINIMUM PULSE
18 : PULSE TRAIN
19 : WINDOW
20 : UP/DWN COUNTER
21 : (A*B)/C ROUND
22 : WINDOW NO HYST
3q
135 INPUT A VALUE FUNC 2 INT -300.00 to 300.00 % 3r
136 INPUT B VALUE FUNC 2 INT -300.00 to 300.00 % 3s
137 INPUT C VALUE FUNC 2 INT -300.00 to 300.00 % 3t
138 OUTPUT VALUE FUNC 2 INT xxx.xx % 3u Output
139 TYPE VALUE FUNC 2 ENUM Same as tag 134 3v
140 INPUT A VALUE FUNC 3 INT -300.00 to 300.00 % 3w
141 INPUT B VALUE FUNC 3 INT -300.00 to 300.00 % 3x
142 INPUT C VALUE FUNC 3 INT -300.00 to 300.00 % 3y
143 OUTPUT VALUE FUNC 3 INT xxx.xx % 3z Output
144 TYPE VALUE FUNC 3 ENUM Same as tag 134 40
145 INPUT A VALUE FUNC 4 INT -300.00 to 300.00 % 41
146 INPUT B VALUE FUNC 4 INT -300.00 to 300.00 % 42
147 INPUT C VALUE FUNC 4 INT -300.00 to 300.00 % 43
148 OUTPUT VALUE FUNC 4 INT xxx.xx % 44 Output
149 TYPE VALUE FUNC 4 ENUM Same as tag 134 45
150 INPUT A VALUE FUNC 5 INT -300.00 to 300.00 % 46
151 INPUT B VALUE FUNC 5 INT -300.00 to 300.00 % 47
152 INPUT C VALUE FUNC 5 INT -300.00 to 300.00 % 48
153 OUTPUT VALUE FUNC 5 INT xxx.xx % 49 Output
154 TYPE VALUE FUNC 5 ENUM Same as tag 134 4a
155 INPUT A VALUE FUNC 6 INT -300.00 to 300.00 % 4b
156 INPUT B VALUE FUNC 6 INT -300.00 to 300.00 % 4c
157 INPUT C VALUE FUNC 6 INT -300.00 to 300.00 % 4d
158 OUTPUT VALUE FUNC 6 INT xxx.xx % 4e Output
159 TYPE VALUE FUNC 6 ENUM Same as tag 134 4f
160 INPUT A VALUE FUNC 7 INT -300.00 to 300.00 % 4g
161 INPUT B VALUE FUNC 7 INT -300.00 to 300.00 % 4h
162 INPUT C VALUE FUNC 7 INT -300.00 to 300.00 % 4i
163 OUTPUT VALUE FUNC 7 INT xxx.xx % 4j Output
