SSD 605C - Page 168

10-6 Parameter Specification
605C Frequency Inverter
Tag (MMI) Name Block Type Range ID Notes
164 TYPE VALUE FUNC 7 ENUM Same as tag 134 4k
165 INPUT A VALUE FUNC 8 INT -300.00 to 300.00 % 4l
166 INPUT B VALUE FUNC 8 INT -300.00 to 300.00 % 4m
167 INPUT C VALUE FUNC 8 INT -300.00 to 300.00 % 4n
168 OUTPUT VALUE FUNC 8 INT xxx.xx % 4o Output
169 TYPE VALUE FUNC 8 ENUM Same as tag 134 4p
170 INPUT A VALUE FUNC 9 INT -300.00 to 300.00 % 4q
171 INPUT B VALUE FUNC 9 INT -300.00 to 300.00 % 4r
172 INPUT C VALUE FUNC 9 INT -300.00 to 300.00 % 4s
173 OUTPUT VALUE FUNC 9 INT xxx.xx % 4t Output
174 TYPE VALUE FUNC 9 ENUM Same as tag 134 4u
175 INPUT A VALUE FUNC 10 INT -300.00 to 300.00 % 4v
176 INPUT B VALUE FUNC 10 INT -300.00 to 300.00 % 4w
177 INPUT C VALUE FUNC 10 INT -300.00 to 300.00 % 4x
178 OUTPUT VALUE FUNC 10 INT xxx.xx % 4y Output
179 TYPE VALUE FUNC 10 ENUM Same as tag 134 4z
180 INPUT A LOGIC FUNC 1 BOOL FALSE / TRUE 50
181 INPUT B LOGIC FUNC 1 BOOL FALSE / TRUE 51
182 INPUT C LOGIC FUNC 1 BOOL FALSE / TRUE 52
183 OUTPUT LOGIC FUNC 1 BOOL FALSE / TRUE 53 Output
184 TYPE LOGIC FUNC 1 ENUM 0 : NOT(A)
1 : AND(A,B,C)
2 : NAND(A,B,C)
3 : OR(A,B,C)
4 : NOR(A,B,C)
5 : XOR(A,B)
6 : 0-1 EDGE(A)
7 : 1-0 EDGE(A)
8 : AND(A,B,!C)
9 : OR(A,B,!C)
10 : S FLIP-FLOP
11 : R FLIP-FLOP
54
185 INPUT A LOGIC FUNC 2 BOOL FALSE / TRUE 55
186 INPUT B LOGIC FUNC 2 BOOL FALSE / TRUE 56
187 INPUT C LOGIC FUNC 2 BOOL FALSE / TRUE 57
188 OUTPUT LOGIC FUNC 2 BOOL FALSE / TRUE 58 Output
189 TYPE LOGIC FUNC 2 ENUM Same as tag 184 59
190 INPUT A LOGIC FUNC 3 BOOL FALSE / TRUE 5a
191 INPUT B LOGIC FUNC 3 BOOL FALSE / TRUE 5b
192 INPUT C LOGIC FUNC 3 BOOL FALSE / TRUE 5c
193 OUTPUT LOGIC FUNC 3 BOOL FALSE / TRUE 5d Output
194 TYPE LOGIC FUNC 3 ENUM Same as tag 184 5e
195 INPUT A LOGIC FUNC 4 BOOL FALSE / TRUE 5f
196 INPUT B LOGIC FUNC 4 BOOL FALSE / TRUE 5g
197 INPUT C LOGIC FUNC 4 BOOL FALSE / TRUE 5h
198 OUTPUT LOGIC FUNC 4 BOOL FALSE / TRUE 5i Output
199 TYPE LOGIC FUNC 4 ENUM Same as tag 184 5j
200 INPUT A LOGIC FUNC 5 BOOL FALSE / TRUE 5k
201 INPUT B LOGIC FUNC 5 BOOL FALSE / TRUE 5l
202 INPUT C LOGIC FUNC 5 BOOL FALSE / TRUE 5m
203 OUTPUT LOGIC FUNC 5 BOOL FALSE / TRUE 5n Output
204 TYPE LOGIC FUNC 5 ENUM Same as tag 184 5o
