Parameter Specification 10-7
605C Frequency Inverter
Tag (MMI) Name Block Type Range ID Notes
205 INPUT A LOGIC FUNC 6 BOOL FALSE / TRUE 5p
206 INPUT B LOGIC FUNC 6 BOOL FALSE / TRUE 5q
207 INPUT C LOGIC FUNC 6 BOOL FALSE / TRUE 5r
208 OUTPUT LOGIC FUNC 6 BOOL FALSE / TRUE 5s Output
209 TYPE LOGIC FUNC 6 ENUM Same as tag 184 5t
210 INPUT A LOGIC FUNC 7 BOOL FALSE / TRUE 5u
211 INPUT B LOGIC FUNC 7 BOOL FALSE / TRUE 5v
212 INPUT C LOGIC FUNC 7 BOOL FALSE / TRUE 5w
213 OUTPUT LOGIC FUNC 7 BOOL FALSE / TRUE 5x Output
214 TYPE LOGIC FUNC 7 ENUM Same as tag 184 5y
215 INPUT A LOGIC FUNC 8 BOOL FALSE / TRUE 5z
216 INPUT B LOGIC FUNC 8 BOOL FALSE / TRUE 60
217 INPUT C LOGIC FUNC 8 BOOL FALSE / TRUE 61
218 OUTPUT LOGIC FUNC 8 BOOL FALSE / TRUE 62 Output
219 TYPE LOGIC FUNC 8 ENUM Same as tag 184 63
220 INPUT A LOGIC FUNC 9 BOOL FALSE / TRUE 64
221 INPUT B LOGIC FUNC 9 BOOL FALSE / TRUE 65
222 INPUT C LOGIC FUNC 9 BOOL FALSE / TRUE 66
223 OUTPUT LOGIC FUNC 9 BOOL FALSE / TRUE 67 Output
224 TYPE LOGIC FUNC 9 ENUM Same as tag 184 68
225 INPUT A LOGIC FUNC 10 BOOL FALSE / TRUE 69
226 INPUT B LOGIC FUNC 10 BOOL FALSE / TRUE 6a
227 INPUT C LOGIC FUNC 10 BOOL FALSE / TRUE 6b
228 OUTPUT LOGIC FUNC 10 BOOL FALSE / TRUE 6c Output
229 TYPE LOGIC FUNC 10 ENUM Same as tag 184 6d
230 OP VERSION OP STATION WORD 0000 to FFFF 6e Output
231 DISABLED TRIPS TRIPS STATUS WORD 0000 to FFFF 6f
234 EXTERNAL TRIP I/O TRIPS BOOL FALSE / TRUE 6i 1
235 INPUT 1 BREAK I/O TRIPS BOOL FALSE / TRUE 6j 1
236 INPUT 2 BREAK I/O TRIPS BOOL FALSE / TRUE 6k 1
237 I*T THRESHOLD I*T TRIP INT 50.00 to 105.00 % 6l
238 I*T TIME I*T TRIP USINT 5 to 60 s 6m
239 I*T UPPER LIMIT I*T TRIP INT 50.00 to 150.00 % 6n
240 STALL LIMIT STALL TRIP INT 50.00 to 150.00 % 6o
241 STALL TIME STALL TRIP INT 0.1 to 3000.0 s 6p
242 POWER FACTOR CURRENT FEEDBACK USINT 0.50 to 0.95 6q 3, 7
243 TRIM IN LOCAL REFERENCE BOOL FALSE / TRUE 6r
244 RAMP TYPE SYSTEM RAMP ENUM 0 : LINEAR
1 : S
6s
245 REMOTE SETPOINT REFERENCE INT -300.00 to 300.00 % 6t
246 JOG SETPOINT JOG INT 0.00 to 100.00 % 6u
247 LOCAL SETPOINT REFERENCE INT 0.00 to 100.00 % 6v Output, 2
248 SPEED TRIM REFERENCE INT -300.00 to 300.00 % 6w
249 REMOTE REVERSE REFERENCE BOOL FALSE / TRUE 6x
250 LOCAL REVERSE REFERENCE BOOL FALSE / TRUE 6y Output, 2
252 MAX SPEED CLAMP REFERENCE INT 0.00 to 100.00 % 70
253 MIN SPEED CLAMP REFERENCE INT -100.00 to 0.00 % 71
254 SPEED SETPOINT REFERENCE INT xxx.xh % (h) 72 Output
To Next Page
