10-8 Parameter Specification
605C Frequency Inverter
Tag (MMI) Name Block Type Range ID Notes
255 SPEED DEMAND REFERENCE INT xxx.xh % (h) 73 Output
256 REVERSE REFERENCE BOOL FALSE / TRUE 74 Output
257 REMOTE REF LOCAL CONTROL BOOL FALSE / TRUE 75 Output
258 RAMP ACCEL RATE SYSTEM RAMP INT 0.0 to 600.0 s 76
259 RAMP DECEL RATE SYSTEM RAMP INT 0.0 to 600.0 s 77
260 RAMP HOLD SYSTEM RAMP BOOL FALSE / TRUE 78
261 JOG ACCEL RATE JOG INT 0.0 to 600.0 s 79
262 JOG DECEL RATE JOG INT 0.0 to 600.0 s 7a
263 STOP RATE STOP INT 0.0 to 600.0 s 7b
264 FAST STOP RATE STOP INT 0.0 to 600.0 s 7c
265 REF MODES LOCAL CONTROL ENUM 0 : LOCAL/REMOTE
1 : LOCAL ONLY
2 : REMOTE ONLY
7d 7
266 STOP ZERO SPEED STOP INT 0.00 to 100.00 % 7e
267 RAMP SYM RATE SYSTEM RAMP INT 0.0 to 600.0 s 7f
268 RAMP SYM MODE SYSTEM RAMP BOOL FALSE / TRUE 7g
269 COMMS SETPOINT REFERENCE INT -300.00 to 300.00 % 7h 1, 4, 5
270 COMMS REF COMMS CONTROL BOOL FALSE / TRUE 7i Output
272 COMMS STATUS COMMS CONTROL WORD 0000 to FFFF 7k Output
273 COMMS COMMAND COMMS CONTROL WORD 0000 to FFFF 7l Output
274 HEALTHY SEQUENCING LOGIC BOOL FALSE / TRUE 7m Output
275 FAST STOP LIMIT STOP INT 0.0 to 3000.0 s 7n
276 DRIVE ENABLE SEQUENCING LOGIC BOOL FALSE / TRUE 7o
277 /FAST STOP SEQUENCING LOGIC BOOL FALSE / TRUE 7p
278 /COAST STOP SEQUENCING LOGIC BOOL FALSE / TRUE 7q
279 RUN STOP MODE STOP ENUM 0 : RAMPED
1 : COAST
2 : DC INJECTION
7r 7
280 JOG SEQUENCING LOGIC BOOL FALSE / TRUE 7s 1
281 SEQ DIRECTION LOCAL CONTROL BOOL FALSE / TRUE 7t 7
282 REM TRIP RESET SEQUENCING LOGIC BOOL FALSE / TRUE 7u 1
283 POWER UP START SEQUENCING LOGIC BOOL FALSE / TRUE 7v
284 STOP DELAY STOP INT 0.000 to 30.000 s 7w
285 RUNNING SEQUENCING LOGIC BOOL FALSE / TRUE 7x Output
286 OUTPUT CONTACTOR SEQUENCING LOGIC BOOL FALSE / TRUE 7y Output
287 READY SEQUENCING LOGIC BOOL FALSE / TRUE 7z Output
288 SWITCH ON ENABLE SEQUENCING LOGIC BOOL FALSE / TRUE 80 Output
289 TRIPPED SEQUENCING LOGIC BOOL FALSE / TRUE 81 Output
290 TRIP RST BY RUN SEQUENCING LOGIC BOOL FALSE / TRUE 82
291 RUN FWD SEQUENCING LOGIC BOOL FALSE / TRUE 83 1
292 RUN REV SEQUENCING LOGIC BOOL FALSE / TRUE 84 1
293 /STOP SEQUENCING LOGIC BOOL FALSE / TRUE 85 1
294 REMOTE REVERSE SEQUENCING LOGIC BOOL FALSE / TRUE 86
295 COMMS SEQ COMMS CONTROL BOOL FALSE / TRUE 87 Output
296 REMOTE REV OUT SEQUENCING LOGIC BOOL FALSE / TRUE 88 Output
297 REMOTE SEQ LOCAL CONTROL BOOL FALSE / TRUE 89 Output
298 SEQ MODES LOCAL CONTROL ENUM Same as tag 265 8a 7
299 POWER UP MODE LOCAL CONTROL ENUM 0 : LOCAL
1 : REMOTE
2 : AUTOMATIC
8b
