Parameter Specification 10-9
605C Frequency Inverter
Tag (MMI) Name Block Type Range ID Notes
300 REMOTE COMMS SEL COMMS CONTROL BOOL FALSE / TRUE 8c 7
301 MAIN SEQ STATE SEQUENCING LOGIC ENUM 0 : NOT READY
1 : START DISABLED
2 : START ENABLED
3 : SWITCHED ON
4 : ENABLED
5 : F-STOP ACTIVE
6 : TRIP ACTIVE
7 : TRIPPED
8d Output
302 JOGGING SEQUENCING LOGIC BOOL FALSE / TRUE 8e Output
303 STOPPING SEQUENCING LOGIC BOOL FALSE / TRUE 8f Output
304 FAST STOP MODE STOP ENUM 0 : RAMPED
1 : COAST
8g 7
305 SYSTEM RESET SEQUENCING LOGIC BOOL FALSE / TRUE 8h Output
306 SWITCHED ON SEQUENCING LOGIC BOOL FALSE / TRUE 8i Output
307 REMOTE SEQ MODES COMMS CONTROL ENUM 0 : TERMINALS/COMMS
1 : TERMINALS ONLY
2 : COMMS ONLY
8j 7
308 REMOTE REF MODES COMMS CONTROL ENUM Same as tag 307 8k 7
309 COMMS TIMEOUT COMMS CONTROL INT 0.0 to 600.0 s 8l
310 PID SETPOINT PID INT -300.00 to 300.00 % 8m
311 PID ENABLE PID BOOL FALSE / TRUE 8n
312 PID INTEGRAL OFF PID BOOL FALSE / TRUE 8o
313 PID P GAIN PID INT 0.0 to 100.0 8p
314 PID I TIME CONST PID INT 0.01 to 100.00 s 8q
315 PID D TIME CONST PID INT 0.000 to 10.000 s 8r
316 PID FILTER TC PID INT 0.000 to 10.000 s 8s
317 PID OUT POS LIM PID INT 0.00 to 105.00 % 8t
318 PID OUT NEG LIM PID INT -105.00 to 0.00 % 8u
319 PID OUT SCALING PID INT -3.0000 to 3.0000 8v
320 PID OUTPUT PID INT xxx.xx % 8w Output
321 COEFFICIENT A CUSTOM SCREEN 1 INT -30000 to 30000 8x
322 COEFFICIENT C CUSTOM SCREEN 1 INT -30000 to 30000 8y
323 UNITS CUSTOM SCREEN 1 STRING 5 characters 8z 5, 6
324 NAME CUSTOM SCREEN 1 STRING 16 characters 90 5, 6
325 RAISE/LOWER OUT RAISE/LOWER INT xxx.xx % 91 Output, 2
326 RL RAMP RATE RAISE/LOWER INT 0.0 to 600.0 s 92
327 RAISE INPUT RAISE/LOWER BOOL FALSE / TRUE 93
328 LOWER INPUT RAISE/LOWER BOOL FALSE / TRUE 94
329 RL MIN VALUE RAISE/LOWER INT -300.00 to 300.00 % 95
330 RL MAX VALUE RAISE/LOWER INT -300.00 to 300.00 % 96
331 RL RESET VALUE RAISE/LOWER INT -300.00 to 300.00 % 97
332 RL RESET RAISE/LOWER BOOL FALSE / TRUE 98
334 DECIMAL PLACE CUSTOM SCREEN 1 ENUM 0 : XXXXX.
1 : XXXX.X
2 : XXX.XX
3 : XX.XXX
4 : X.XXXX
5 : XXXX._
6 : XXX.X_
7 : XX.XX_
8 : X.XXX_
9a
335 MIN SPEED OUTPUT MINIMUM SPEED INT xxx.xx % 9b Output
336 MIN SPEED INPUT MINIMUM SPEED INT -300.00 to 300.00 % 9c
337 MIN SPEED MINIMUM SPEED INT -100.00 to 100.00 % 9d
To Next Page
