Programming Your Application 6-71
605C Frequency Inverter
Functional Description
The table below shows the possible parameter values for FIRST TRIP, and the TRIPS
HISTORY function block. Also shown is whether or not the trip may be disabled.
Trip name Enumerated value May be Disabled
NO TRIP 0 N/A
LINK OVERVOLTS 1 No
LINK UNDERVOLT 2 No
OVERCURRENT 3 No
HEATSINK TEMP 4 No
EXTERNAL TRIP 5 Yes
INPUT 1 BREAK 6 Yes
INPUT 2 BREAK 7 Yes
MOTOR STALLED 8 Yes
I*T TRIP 9 No
BRAKE RESISTOR 10 Yes
BRAKE SWITCH 11 Yes
OP STATION 12 Yes
LOST COMMS 13 Yes
14
15
16
MOTOR TEMP 17 Yes
CURRENT LIMIT 18 No
SHORT CIRCUIT 19 No
24V FAILURE 20 Yes
LOW SPEED I 21 No
PHASE FAIL 22 Yes
Hexadecimal Representation of Trips
The ACTIVE TRIPS, WARNINGS and DISABLED TRIPS parameters use a four digit
hexadecimal number to identify individual trips. Each trip has a unique corresponding number.
Refer to “Hexadecimal Representation of Trips” at the beginning of this Chapter.
