Functional Description
OUTPUT is generated from the inputs according to the operation type selected. The output is
always limited to be within the range -300.00% to +300.00%.
Operation Description
IF(C) -A If INPUT C is not zero the OUTPUT is minus INPUT A, otherwise the
OUTPUT is the same as INPUT A.
ABS(A+B+C) The OUTPUT is set to the absolute value of INPUT A + INPUT B + INPUT
C.
SWITCH(A,B)
O
UTPUT
INPUT A
INPUT B
INPUT C
If INPUT C is zero the
OUTPUT is set to INPUT A,
otherwise the output is set to
INPUT B
(A*B)/C The OUTPUT is set to (INPUT A * INPUT B) / (INPUT C). The algorithm
compensates for the remainder term.
Parameter Descriptions
INPUT A
Range: -300.00 to 300.00 %
General purpose input.
INPUT B
Range: -300.00 to 300.00 %
General purpose input.
INPUT C
Range: -300.00 to 300.00 %
General purpose input.
TYPE
Range: Enumerated - see
below
The operation to be performed on the three inputs to produce the output value.
Enumerated Value : Type
0 : IF(C) -A
1 : ABS(A+B+C)
2 : SWITCH(A,B)
3 : (A*B)/C
4 : A+B+C
5 : A-B-C
6 : B<=A<=C
7 : A>B+/-C
8 : A>=B
9 : ABS(A)>B+/-C
10 : ABS(A)>=B
11 : A(1+B)
12 : IF(C) HOLD(A)
13 : BINARY DECODE
14 : ON DELAY
15 : OFF DELAY
16 : TIMER
17 : MINIMUM PULSE
18 : PULSE TRAIN
19 : WINDOW
20 : UP/DWN COUNTER
21 : (A*B)/C ROUND
22 : WINDOW NO HYST
OUTPUT
Range: xxx.xx %
The result of performing the selected operation on the inputs.
