SSD 605C - Page 183

Parameter Specification 10-21
605C Frequency Inverter
500V Build AC Supply Voltage and
Power Rating Dependant
Defaults
Tag 5.5kW
500V
7.5kW
500V
11kW
500V
FULL LOAD CALIB 64 9.0 11.7 16.0
NO LOAD CALIB 65 5.4 6.5 8.2
STATOR RES 119 3.83 3.19 2.55
LEAKAGE INDUC 120 40.7 33.9 27.0
MUTUAL INDUC 121 365.9 304.7 243.1
MOTOR VOLTS 122 500.0 500.0 500.0
MOTOR CONNECTION 124 DELTA DELTA DELTA
POWER FACTOR 242 0.80 0.83 0.86
NAMEPLATE RPM 83 1445 1450 1460
SLIP MOTOR LIMIT 85 82.5 75.0 60.0
SLIP REGEN LIMIT 86 82.5 75.0 60.0
DEFLUX DELAY 100 2.0 2.0 2.0
DEFLUX TIME 710 0.5 0.5 0.5
FLY SEARCH BOOST 32 40.00 40.00 40.00
FLY SEARCH VOLTS 573 9.00 9.00 9.00
FLY SEARCH TIME 574 10.0 10.0 10.0
INJ FREQUENCY 577 9.0 9.0 9.0
INJ DC PULSE 579 2.0 2.0 2.0
INJ FINAL DC 580 1.0 1.0 1.0
INJ DC LEVEL 581 4.00 4.00 4.00
INJ BASE VOLTS 739 100.00 100.00 100.00
ACCEL RATE 258 10.00 10.0 10.0
DECEL RATE 259 10.00 10.0 10.0
SYMMETRIC RATE 267 10.00 10.0 10.0
