SSD 605C - Page 59

The Operator Station 5-9
605C Frequency Inverter
FIRST TRIPS Tag No. 6 enumerated
Indictes the source of the first trip from when a trip occurs.
(Refer to the TRIPS STATUS function block)
AIN 1 VALUE Tag No. 16 xxx.xx%
The input reading with scaling and input applied.
(Refer to the ANALOG INPUT function block)
AIN 2 VALUE Tag No. 25 xxx.xx%
The input reading with scaling and input applied.
(Refer to the ANALOG INPUT function block)
AIN 3 VALUE Tag No. 715 xxx.xx%
The input reading with scaling and input applied.
(Refer to the ANALOG INPUT function block)
AIN 4 VALUE Tag No. 722 xxx.xx%
The input reading with scaling and input applied.
(Refer to the ANALOG INPUT function block)
DIN 1 VALUE Tag No. 31 FALSE / TRUE
The TRUE or FALSE input (after any inversion).
(Refer to the DIGITAL INPUT function block)
DIN 2 VALUE Tag No. 34 FALSE / TRUE
The TRUE or FALSE input (after any inversion).
(Refer to the DIGITAL INPUT function block)
DIN 3 VALUE Tag No. 37 FALSE / TRUE
The TRUE or FALSE input (after any inversion).
(Refer to the DIGITAL INPUT function block)
DIN 4 VALUE Tag No. 40 FALSE / TRUE
The TRUE or FALSE input (after any inversion).
(Refer to the DIGITAL INPUT function block)
DIN 5 VALUE Tag No. 43 FALSE / TRUE
The TRUE or FALSE input (after any inversion).
(Refer to the DIGITAL INPUT function block)
DIN 6 VALUE Tag No. 726 FALSE / TRUE
The TRUE or FALSE input (after any inversion).
(Refer to the DIGITAL INPUT function block)
DIN 7 VALUE Tag No. 728 FALSE / TRUE
The TRUE or FALSE input (after any inversion).
(Refer to the DIGITAL INPUT function block)
DIN 8 VALUE Tag No. 730 FALSE / TRUE
The TRUE or FALSE input (after any inversion).
(Refer to the DIGITAL INPUT function block)
AOUT 1 VALUE Tag No. 45 -300.00 to 300.00%
The demanded value to output.
(Refer to the ANALOG OUTPUT function block)
AOUT 2 VALUE Tag No. 731 -300.00 to 300.00%
The demanded value to output.
(Refer to the ANALOG OUTPUT function block)
DOUT1 VALUE Tag No. 52 FALSE / TRUE
The True or False output demand.
(Refer to the DIGITAL OUTPUT function block)
DOUT 2 VALUE Tag No. 55 FALSE / TRUE
The True or False output demand.
(Refer to the DIGITAL OUTPUT function block
DOUT 3 VALUE Tag No. 737 FALSE / TRUE
The True or False output demand.
(Refer to the DIGITAL OUTPUT function block
