Independent watchdog (IWDG) UM0306

144/519

10.3 IWDG register map

Refer to Table 1 on page 27 for the register boundary addresses.

Table 34. IWDG register map and reset values

Offset Register

00h

IWDG_KR

Reserved

KEY[15:0]

Reset Value 0000000000000000

04h

IWDG_PR

Reserved

PR[2:0]

Reset Value 000

08h

IWDG_RLR

Reserved

RL[11:0]

Reset Value 111111111111

0Ch

IWDG_SR

Reserved

RVU

PVU

Reset Value 00
