UM0306 USB full speed device interface (USB)

445/519

Table 60. Endpoint type encoding

EP_TYPE[1:0] Meaning

00 BULK

01 CONTROL

10 ISO

11 INTERRUPT

Table 61. Endpoint kind meaning

EP_TYPE[1:0] EP_KIND Meaning

00 BULK DBL_BUF

01 CONTROL STATUS_OUT

10 ISO Not used

11 INTERRUPT Not used

Table 62. Transmission status encoding

STAT_TX[1:0] Meaning

00 DISABLED: all transmission requests addressed to this endpoint are ignored.

STALL: the endpoint is stalled and all transmission requests result in a STALL

handshake.

NAK: the endpoint is naked and all transmission requests result in a NAK

handshake.

11 VALID: this endpoint is enabled for transmission.
