Inter-integrated circuit (I2C) interface UM0306

344/519

15.5 Interrupt requests

Note: 1 SB, ADDR, ADD10, STOPF, BTF, RxNE and TxE are logically ORed on the same interrupt

channel.

2 BERR, ARLO, AF, OVR, PECERR, TIMEOUT and SMBALERT are logically ORed on the

same interrupt channel.

Table 46. I

C Interrupt requests

Interrupt Event

Event

Flag

Enable

Control

Bit

Start bit sent (Master) SB

ITEVFEN

Address sent (Master) or Address matched (Slave) ADDR

10-bit header sent (Master) ADD10

Stop received (Slave) STOPF

Data Byte Transfer Finished BTF

Receive buffer not empty RxNE

ITEVFEN and

ITBUFEN

Transmit buffer empty TxE

Bus error BERR

ITERREN

Arbitration loss (Master) ARLO

Acknowledge failure AF

Overrun/Underrun OVR

PEC error PECERR

Timeout/Tlow error TIMEOUT

SMBus Alert SMBALERT
