Window watchdog (WWDG) UM0306

150/519

11.7 WWDG register map

Refer to Table 1 on page 27 for the register boundary addresses.

Table 35. WWDG register map and reset values

Offset Register

00h

WWDG_CR

Reserved

WDGA

T[6:0]

Reset Value 01111111

04h

WWDG_CFR

Reserved

EWI

WDGTB1

WDGTB0

W[6:0]

Reset Value 0001111111

08h

WWDG_SR

Reserved

EWIF

Reset Value 0
