UM0306 General purpose timer (TIMx)

231/519

Figure 88. Counter timing diagram, internal clock divided by 4, TIMx_ARR=0x36

Figure 89. Counter timing diagram, internal clock divided by N

Figure 90. Counter timing diagram, Update event with ARPE=1 (counter underflow)

CK_INT

0036 0035

CNT_EN

TIMER CLOCK = CK_CNT

COUNTER REGISTER

UPDATE INTERRUPT FLAG (UIF)

0034

0035

COUNTER OVERFLOW (cnt_ovf)

UPDATE EVENT (UEV)

Note: Here, center-aligned mode 2 or 3 is used with an UIF on overflow

TIMER CLOCK = CK_CNT

COUNTER REGISTER

UPDATE INTERRUPT FLAG (UIF)

COUNTER UNDERFLOW

UPDATE EVENT (UEV)

CK_INT

CNT_EN

TIMER CLOCK = CK_CNT

COUNTER REGISTER

UPDATE INTERRUPT FLAG (UIF)

COUNTER UNDERFLOW

UPDATE EVENT (UEV)

01 02 03 04 05 06 0705 04 03 02 0106

AUTO-RELOAD PRELOAD REGISTER

FD 36

Write a new value in TIMx_ARR

AUTO-RELOAD ACTIVE REGISTER

FD 36

CK_INT
