General purpose and alternate function I/O (GPIO and AFIO) UM0306
86/519
5.2.7 Port configuration lock register (GPIOx_LCKR) (x=A..E)
This register is used to lock the configuration of the port bits when a correct write sequence
is applied to bit 16 (LCKK). The value of bits [15:0] is used to lock the configuration of the
GPIO. During the write sequence, the value of LCKR[15:0] must not change. When the
LOCK sequence has been applied on a port bit it is no longer possible to modify the value of
the port bit until the next reset.
Each lock bit freezes the corresponding 4 bits of the control register (CRL, CRH).
Address Offset: 18h
Reset value: 0000 0000h
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved LCKK
rw
1514131211109876543210
LCK15 LCK14 LCK13 LCK12 LCK11 LCK10 LCK9 LCK8 LCK7 LCK6 LCK5 LCK4 LCK3 LCK2 LCK1 LCK0
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:17 Reserved
Bit 16
LCKK[15:0]: Lock key
This bit can be read anytime. It can only be modified using the Lock Key
Writing Sequence.
0: Port configuration lock key not active
1: Port configuration lock key active. GPIOx_LCKR register is locked until an
MCU reset occurs.
LOCK Key Writing Sequence:
Write 1
Write 0
Write 1
Read 0
Read 1 (this read is optional but confirms that the lock is active)
Notes:
During the LOCK Key Writing sequence, the value of LCK[15:0] must not
change.
Any error in the lock sequence will abort the lock.
Bits 15:0
LCKx: Lock bit x (x= 0 .. 15)
These bits are read write but can only be written when the LCKK bit is 0.
0: Port configuration not locked
1: Port configuration locked.
