UM0306 Advanced control timer (TIM1)
215/519
12.5.17 Capture/compare register 4 (TIM1_CCR4)
Address offset: 40h
Reset value: 0000h
1514131211109876543210
CCR4[15:0]
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 15:0
CCR4[15:0]: Capture/Compare Value.
If channel CC4 is configured as output:
CCR4 is the value to be loaded in the actual capture/compare 4 register (preload
value).
It is loaded permanently if the preload feature is not selected in the TIM1_CCMR4
register (bit OC4PE). Else the preload value is copied in the active capture/compare 4
register when an update event occurs.
The active capture/compare register contains the value to be compared to the counter
TIM1_CNT and signalled on OC4 output.
If channel CC4 is configured as input:
CCR4 is the counter value transferred by the last input capture 4 event (IC4).
