General purpose timer (TIMx) UM0306

226/519

Figure 78. Counter timing diagram, internal clock divided by N

Figure 79. Counter timing diagram, Update event when ARPE=0 (TIMx_ARR not

preloaded)

TIMER CLOCK = CK_CNT

COUNTER REGISTER

UPDATE INTERRUPT FLAG (UIF)

COUNTER OVERFLOW

UPDATE EVENT (UEV)

CK_INT

CNT_EN

TIMER CLOCK = CK_CNT

COUNTER REGISTER

UPDATE INTERRUPT FLAG (UIF)

COUNTER OVERFLOW

UPDATE EVENT (UEV)

01 02 03 04 05 06 0732 33 34 35 3631

AUTO-RELOAD REGISTER

FF 36

Write a new value in TIMx_ARR

CK_INT
