UM0306 Inter-integrated circuit (I2C) interface

345/519

Figure 139. I

C interrupt mapping diagram

15.6 I2C register description

Refer to Section 1.1 on page 23 for a list of abbreviations used in register descriptions.

15.6.1 Control register 1(I2C_CR1)

Address offset: 00h

Reset Value: 0000h

ADDR

ADD10

RxNE

TxE

BTF

it_event

ARLO

BERR

OVR

PECERR

TIMEOUT

SMBAlert

ITERREN

it_error

ITEVFEN

ITBUFEN

STOPF

15141312111098 7 6543210

RST

Res. ALERT PEC POS ACK STOP START

STRETCH

ENGC

PEC

ARP

SMB

TYPE

Res.

BUS

rw rw rw rw rw rw rw rw rw rw rw rw rw rw

www.BDTIC.com/ST
